EX-45362IS

1. Description

The EX-45362IS is a plug & play high-speed serial RS-232/422/485 expansion card for
the PCI-Express Bus. The EX-45362IS provides two 9 pin high speed RS-232/422/485
serial ports. It uses data transfer rates up to 921Kbaud/s. The EX-45362IS design utiliz-
es the MOSCHIP chipset with 256-byte buffer, which incorporates the latest in high
speed interface technology. In combination with the fast PCI-Express bus it provides a
secure and very high data transfer on each port. It supports PCI-Express x1 to x16. It is
not possible to change the address or IRQ settings manually, they will be obtained au-
tomatically by the system BIOS and operating system. With the jumpers you can enable
5V or 12V power to pin 9. Please note if you use power to pin 9 your peripheral device
must support it. The serial ports can be configured as RS-232, RS-422, RS-485 2-wire
or RS-485 4-wire. There is additionally a 8 cm low profile slot bracket for installation in
small computer housing. Furthermore, the EX-45362IS is equipped with 15KV ESD
Surge Protection and 2.5KV Optical Isolation.
Features:
•
Compatible for PCI-Express x1 to x16
•
Up to 921.6 Kbps Baud Rate
•
Support RS-232, RS-422, RS-485 2-wire and RS-485 4-wire
•
15KV ESD Surge Protection & 2.5KV Optical Isolation
•
Support Windows 2000/ XP/ Vista/ 7/ 8.x/ 10/ Server 20xx/ Mac/ Linux
•
Zertifiziert für

2. Extent of Delivery

Before you install the EX-45362IS in your PC, you should first check the contents of the
delivery:
•
EX-45362IS
•
Driver CD
•
Manual
•
Octopus Cable
•
Low Profile Bracket
