ABB ACS880-04F Kurzanleitung Für Die Installation Seite 76

76 Figures
E
Drive type Air flow
Heatsink Front
3 3
m /h m /h
U = 400 V
N
ACS880-04F-504A-3 1400 120
ACS880-04F-584A-3 1400 120
ACS880-04F-649A-3 1400 120
ACS880-04F-725A-3 1400 120
ACS880-04F-820A-3 1400 120
ACS880-04F-880A-3 1400 120
U = 500 V
N
ACS880-04F-459A-5 1400 120
ACS880-04F-502A-5 1400 120
ACS880-04F-582A-5 1400 120
ACS880-04F-634A-5 1400 120
ACS880-04F-715A-5 1400 120
ACS880-04F-820A-5 1400 120
ACS880-04F-880A-5 1400 120
U = 690 V
N
ACS880-04F-329A-7 1400 120
ACS880-04F-369A-7 1400 120
ACS880-04F-429A-7 1400 120
ACS880-04F-470A-7 1400 120
ACS880-04F-522A-7 1400 120
ACS880-04F-590A-7 1400 120
ACS880-04F-650A-7 1400 120
ACS880-04F-721A-7 1400 120
(PE) PE (PE) L2 L3
L1
L1
L2 L3
PE
ACS880-04F
L1/ L2/ L3/
UDC-
U1 V1 W1
INPUT
OUTPUT
T1/ T2/ T3/
U2 V2 W2
V1
U1 W1
~
3
M
F
Heat dissipation Type DIN
43653
Heatsink Front
W W
5100 550 170M6012
5800 650 170M6014
7400 750 170M6014
7950 850 170M6016
8950 950 170M6269
H
9600 1000 170M6269
3900 550 170M6010
5050 600 170M6012
5750 700 170M6014
7350 800 170M6014
7900 900 170M6016
8900 1000 170M6269
10050 1050 170M6269
3900 550 170M6011
5050 600 170M6013
5750 700 170M6014
7350 800 170M6015
7900 900 170M6016
8900 1000 170M6017
10050 1050 170M6018
10050 1050 170M6018
I
L
UDC+
PE
R- R+
Washer
M12 or
equal
Hex screw M12×35 full
thread 70 N·m (52 lbf·ft)
J
360 °
Hex nut M12 70 N·m (52 lbf·ft)
G
ohm
U1
V1
ohm
W1
K
Combi screw
M6×12 Torx T25
8 N·m (5.9 lbf·ft)
Combi screw M12×25
Hex (Delta) 70 N·m
(52 lbf·ft)
3
1
2
M
3~
PE
