We wish you much pleasure and success with your new
scheppach machine.
Note
In accordance with valid product liability laws, the manu-
facturer of this device shall not be responsible for damage
to and from this device which results from:
• Improper care.
• Noncompliance with the Operating Instructions.
• Repairs made by unauthorized persons.
• The installation and use of any parts which are not origi-
nal scheppach replacement parts.
• Improper use and application.
• Failure the electrical system as a result of noncompli-
ance with the legal and applicable electrical directives
and VDE regulations 0100, DIN 57113 / VDE 0113.
We recommend
that you read through the entire operating instructions be-
fore putting into operation.
These operating instructions are to assist you in getting
to know your machine and utilize its proper applications.
The operating instructions contain important notes on how
you work with the machine safely, expertly, and economi-
cally, and how you can avoid hazards, save repair costs,
reduce downtime and increase the reliability and service
life of the machine.
In addition to the safety requirements contained in these
operating instructions, you must be careful to observe
your country's applicable regulations.
The operating instructions must always be near the ma-
chine. Put them in a plastic folder to protect them from dirt
and humidity. They must be read by every operator before
beginning work and observed conscientiously. Only per-
sons who have been trained in the use of the machine
and have been informed of the various dangers may work
with the machine. The required minimum age must be ob-
served.
In addition to the safety requirements contained in these
operating instructions and your country's applicable reg-
ulations, you should observe the generally recognized
technical rules concerning the operation of woodworking
machines.
• After unpacking, check all parts for any transport dam-
age. Inform the supplier immediately of any faults.
• Later complaints cannot be considered.
• Make sure the delivery is complete.
• Before putting into operation, familiarize yourself with
the machine by carefully reading these instructions.
• Use only original scheppach accessories, wearing or
replacement parts. You can find replacement parts at
your scheppach dealer.
• When ordering, include our item number and the type
and year of construction of the machine.
10 english
Downloaded from www.Manualslib.com
Manufacturer
Dear customer,
mGeneral notes
manuals search engine
DM460T
Included with delivery
Wood turning machine
Work piece table
Rotating tailstock centre
Independent chuck
Mandrel
Jaw spanner SW 32/41
Hex driver 3/6/8
Operating instructions
Technical data
Dimensions
940 x 270 x 420
L x B x H mm
Bed height mm
Headstock
thread
H e a d s t o c k
taper
Height of
centers above
bed mm
Width between
centers mm
Diameter
above bed mm
Diameter
between
centers mm
Length of tool
holder mm
Weight kg
Wood turning spindle with dust-proof precision grooved ball
bearing
Revolutions
650 / 1000 / 1450 / 2000 / 3000
1/min
Tailstock
Tailstock cone
Tailstock drill
hole (hollow
spindle) ø mm
Tailstock
sleeve
adjustment
mm
Drive
230–240V/50 Hz
Electric Motor
Input P1 kW
Output P2 kW
Revolutions
1/min
M o t o r
protection
Undervoltage
release
Operating
mode
Noise parameters
Acoustic power level in dB
Idling L = 74.3 dB(A),
WA
Operating L = 91.7 dB(A)
WA
Acoustic pressure level in dB
Idling L = 61.3 dB(A),
pAeq
Operating L = 78.7 dB(A)
pAeq
A measuring uncertainty coefficient (K = 3 dB) applies
to the emission values listed above.
Subject to technical modifications!
Carrier
Tappet
190
M 33
MK 2
152
457
305
240
150
34,8
MK 2
9,5
47
0,55
0,30
1400
yes
yes
S1
