ASROCK Q1900DC-ITX Bedienungsanleitung Seite 5

I/O Panel
15
No. Description
1
2
3
4
5
6
7
8
* There are two LEDs on the LAN port. Please refer to the table below for the LAN port LED indications.
ACT/LINK LED
LAN Port
Activity / Link LED
Status
Off
Blinking
On
Downloaded from www.Manualslib.com
1 2
14 13
PS/2 Mouse Port
D-Sub Port
USB 2.0 Ports (USB_34)
LAN RJ-45 Port*
Side Speaker (Gray)
Rear Speaker (Black)
Line In (Light Blue)
Front Speaker (Lime)**
SPEED LED
Description
No Link
Data Activity
Link
manuals search engine
3 4
12 11
No. Description
9 Microphone (Pink)
10 Central / Bass (Orange)
11 USB 3.0 Ports (USB3_34)
12 HDMI Port
13 DVI-D Port
14 PS/2 Keyboard Port
15 DC Jack***
Speed LED
Status Description
Off 10Mbps connection
Orange 100Mbps connection
Green 1Gbps connection
Q1900DC-ITX
5 7
6 8
10 9
3
