– Drive carefully over curbs and gravel roads. The vehicle will be damaged by
repeated impact.
– Make sure your child does not use the footrest to stand on.
– Do not expose the stroller to any artificial heat or direct sunlight.
II. INSTRUcTIoNS FoR maINTENaNcE
– The user is responsible for the regular maintenance of the stroller. all connecting
parts and rivets have to be tightened and secured properly. It is particularly
important to ensure that the locking mechanism and swiveling mechanism are
treated regularly with Teflon spray (dry lubricant). it is important that brakes,
wheels and tyres are not impaired during use. Inspect them regularly and
repair or replace if necessary. STOp using any product that does not appear
structurally sound.
– Do not make any modifications to the product. if you have any complaints or
problems, please contact your supplier or importer.
– a service should be scheduled every 12 months.
– You can also treat the other moving parts with Teflon spray (dry lubricant). After
spraying on the Teflon, wipe the product with a soft cloth.
– Use only original CYBEX replacement parts. It may be unsafe to use substitutes.
– The frame tubes covered by the locking mechanism and turning mechanism
should also be regularly cleaned and sprayed. This will ensure that you enjoy
your stroller without any problems.
cLEaNING
– Do not use abrasives to clean the frame! use a damp cloth and a mild
detergent and dry thoroughly.
– Should the stroller be exposed to salt water, please rinse it down with fresh (tap)
water as soon as possible afterwards.
– The seatcover and the canopy can be washed by hand with mild detergent
(not warmer than 30°C).
– The seatcover is maschine washable (See care label for details). Do not use the
tumble drier. Dry thoroughly before reuse.
– All CYBEX fabrics have been tested, but when the stroller is very wet, the water
may permeate the lining through the bottom edges and seams and leave
water stains on the upholstery. We advise you to use a rain cover to avoid this.
Also please do not fold or store the product while wet. if the stroller is wet, allow
to dry with the hood extended. Never store in a damp environment as this can
cause mildew to form.
Note! Please wash the cover separately before you use it the first time. Do not
tumble dry and do not expose to direct sunlight! Do not iron!
This product was approved according to the EN 1888:2003 + A1/A2/A3:2005
standard.
SERvIcE
In general the Cybex pushchairs will run smooth without any problems. a dry and/
or dusty environment can have a negative effect on the wheel systems. To avoid
this it is very important that the wheel systems will be regularly checked, cleaned
and lubricated. This will ensure a smooth operation of the stroller in daily use.
Please follow the instruction below to maintain the wheel systems (wheel axles &
suspension system).
II.-I check of wheel systems
a) Wheel system must be cleaned before applying the lubricant.
b) Wheel system must not be broken or damaged.
for eliminate squeaking on you CYBEX buggy take only WD 40 and follow the
mentioned pictures below. Do not use any other kind of lubricant! insert always
a cloth or a carton in order to leave no oil stains. please pay special attention
to not apply the lubricant on any other part of the stroller (fabrics, tubes, etc.).
II.-II applying of the lubricant
a) rear Wheel - Spray from the rear side of the buggy in the space between the rim
and the housing on both sides. Let the lubricant get into the system for approx.
10 seconds, and then turn the wheels.
b) front Wheel - Spray in the space between the rim and the housing on both
sides. let the lubricant get into the system for approx. 10 seconds, and then turn
the wheels. Should this not avoid the squeaking, please remove the rim cap
and apply the spray on the axle.
c) Suspension - apply some lubricant between the suspension slider and the
housings.
DISPoSaL
When you are done using your CYBEX ONYX/TOpaz, a proper disposal is important.
garbage disposal can be different in every country. Please contact your local
waste management company to make sure you are taking the right steps to
dispose of the CYBEX ONYX/TOpaz. always follow the disposal regulations of your
country.
III. INSTRUcTIoNS FoR USE
IMpORTaNT: REaD THESE INSTRUCTIONS CaREFULLY BEFORE USE aND KEEp THEM
FOR FUTURE REFERENCE. YOUR CHILDREN'S SaFETY MaY BE aFFECTED IF YOU DO
NOT fOllOW ThESE iNSTruCTiONS.
oNYx/ToPaz aSSEmBLY INSTRUcTIoN
DELIvERY STaTUS
1. oPENING THE STRoLLER
a) Release the folding lock lever.
b) Open the stroller.
c) push the pedal button down until the locking system is engaged.
