Quick Start

To attach the MultiSync
these instructions:
1. Turn off the power to your computer.
If you are using the supplied video signal cable, continue to step 2.
If you are using a BNC cable (not included), please skip to Step 3.
NOTE: BNC cables may be purchased at your local electronics store.
2. For the PC: Connect one end of the video signal cable to the back of the monitor
(Figure A.1) and the other end to the connector of the display card in your system
(Figure A.2). Tighten all screws. Proceed to Step 4.
Connector
Cover
Figure A.1
78133813.wpc
LCD monitor to your system, follow
® ™
1810
3
5
Figure A.2
