Quick Start cont.
For the Mac: Attach one end of the video signal cable to the back of the monitor
(Figure B.1) Connect the Macintosh cable adapter to the computer and the other end of
the Video signal cable to the Macintosh cable adapter (Figure B.2). Tighten all screws.
Proceed to step 4.
NOTE: To obtain the MultiSync
at (800) 820-1230.
Connector
Cover
Figure B.1
78133813.wpc
® LCD ™ Macintosh cable adapter call NEC Technologies
1810
4
6
Figure B.2
