Quick Start cont.
To attach your MultiSync
these instructions:
1. Turn off the power to your computer.
2. For the PC: Connect the 15-pin mini D-SUB of the appropriate signal cable
to the connector of the display card in your system (Figure G.1). Tighten all screws.
For the Mac: Connect the MultiSync Macintosh cable adapter to the computer (Figure
H.1). Attach the 15-pin mini D-SUB end of the appropriate signal cable to the
MultiSync Macintosh cable adapter (Figure H.1). Tighten all screws.
NOTE: To obtain the MultiSync Macintosh cable adapter, call NEC Technologies at
(800) 820-1230.
Figure G.1
78133813.wpc
LCD monitor to your system, follow
® ™
2010
Figure H.1
