U S E R ' S M A N U A L MultiSync ® LCD1830 ™ To learn about other special offers, register online at www.necmitsubishi.com/productregistration LCD1830.wpc 11/29/00, 9:56 AM...
C.S.A. C22.2 No. 950. FCC Information 1. Use the attached specified cables with the MultiSync LCD1830 (LA-18S02 and LA-18S02- BK) color monitor so as not to interfere with radio and television reception. (1) Please use the supplied power cord or equivalent to ensure FCC compliance.
Contents Your new NEC MultiSync ® LCD monitor box* should contain the following: • MultiSync LCD ™ monitor with tilt base 1830 • Power Cord • Video Signal Cable • User’s Manual U S E R ' S M A N U A L MultiSync ®...
MultiSync LCD Macintosh cable adapter (Figure B.1). Tighten all screws. 1830 NOTE: To obtain the MultiSync LCD Macintosh cable adapter, call NEC-Mitsubishi 1830 Electronics Display of America, Inc. at (800) 820-1230. Remove connector cover and cable cover on back of monitor.
Seite 6
Quick Start –continued Figure C.1 AC Power Cord Signal Cable 1. Cables pass through in this hole. 2. Connect each connector 3. Replace connector cover with cables passing through upper opening. Power Outlet AC-IN INPUT2 INPUT1 To Computer Power Switch Figure D.1 LCD1830.wpc 11/29/00, 9:56 AM...
Seite 7
Quick Start –continued Cable Cover Marking How to remove this cover. 1. Push marking area Marking area 2. Slide to up side (1.Push) 3. Remove Push Push Connector Cover How to remove this cover. 1. Push under side 2. Remove Figure E.1 LCD1830.wpc 11/29/00, 9:56 AM...
Seite 8
Quick Start –continued Tilt Grasp both sides of the monitor screen with your hands and adjust the tilt as desired (Figure TS.1). Figure TS.1 Remove Monitor Stand for Mounting To prepare the monitor for alternate mounting purposes: 1. Remove the connector cover, hinge cover and cable cover (Figure R.1).
Controls OSM™ (On-Screen Manager) control buttons on the front of the monitor function as follows: To access OSM menu, press any of the control buttons ( , ). To change signal input, press the INPUT 1/2 button. Main Menu Sub-Menu EXIT Exits the OSM controls.
Seite 10
Controls –continued Image Adjust Controls H.SIZE Adjusts the horizontal size by increasing or decreasing this setting. FINE Improves focus, clarity and image stability by increasing or decreasing this setting. AUTO ADJUST Automatically adjusts H. SIZE and FINE settings. AccuColor ® Control Systems Six color presets select the desired color setting (two of the color presets are standard and cannot be changed).
Seite 11
Controls –continued Tools 2 LANGUAGE: OSM ™ control menus are available in seven languages. OSM POSITION: You can choose where you would like the OSM control image to appear on your screen. Selecting OSM Location allows you to manually adjust the position of the OSM control menu left, right, up or down. OSM TURN OFF: The OSM control menu will stay on as long as it is use.
Recommended Use Safety Precautions and Maintenance FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE FOLLOWING WHEN SETTING UP AND USING THE MULTISYNC ® LCD COLOR MONITOR: • DO NOT OPEN THE MONITOR. There are no user serviceable parts inside and opening or removing covers may expose you to dangerous shock hazards or other risks.
Seite 13
Do not use primary color blue on a dark background, as it is difficult to see and may produce eye fatigue to insufficient contrast For more detailed information on setting up a healthy work environment, call NEC at (800) 820-1230, NEC FastFacts information at (800) 366-0476 and request ™...
1152 x 864* at 75Hz 1152 x 900* at 66Hz NEC-Mitsubishi Electronics Display cites 1280 x 960* at 60Hz to 75Hz recommended resolution at 60 Hz for 1280 x 1024 at 60 Hz to 76 Hz ....optimal display performance.
VESA standard third party mounting arm or bracket. Allows for the monitor to be mounted on a wall or an arm using any third party compliant device. OSM Display Screen Copyright 2000 by NEC-Mitsubishi Electronics Display of America, Inc. LCD1830.wpc 11/29/00, 9:56 AM...
NOTE: As with all personal display devices, NEC-Mitsubishi Electronics Display of America recommends using a screen saver at regular intervals whenever the screen is idle.
References • BBS (978) 742-8706 NEC-Mitsubishi Electronics Display of America Remote Bulletin Board System is an electronic service accessible with your system and a modem. Communica- tion parameters are: 300/1200/2400/9600/14.4k/28.8k/33.6k bps, no parity, 8-data bits, 1 stop bit • Customer Service/...
Product may vary. Therefore, suitability of a Product for a specific purpose or application must be determined by consumer and is not warranted by NMD-A. For the name of your nearest authorized NEC-Mitsubishi Electronics Display service facility, contact NEC-Mitsubishi Electronics Display of America at 1-800-632-4662. LCD1830.wpc...
TCO’95 MultiSync LCD1830 Black Model (LA-18S02-BK) Congratulations! You have just purchased a TCO’95 approved and labeled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also, to the further development of environmentally adapted electronics products.
TCO’95 –continued reproductive damage in fisheating birds and mammals, due to the bio-accumulative* processes. Flame retardants have been found in human blood and researchers fear that disturbances in foetus development may occur. TCO’95 demand requires that plastic components weighing more than 25 grams must not contain organically bound chlorine and bromine.
TCO’99 MultiSync LCD1830 White Model (LA-18S02) Congratulations! You have just purchased a TCO’99 approved and labeled product! Your choice has provided you with a product devel- oped for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.
Seite 22
TCO’99 –continued accumulative* processes. Flame retardants have been found in human blood and researchers fear that disturbances in foetus development may occur. TCO’99 demand requires that plastic components weighing more than 25 grams must not contain flame retardants with organically bound chlorine and bromine. Flame retardants are allowed in the printed circuit boards since no substitutes are available.
AVERTISSEMENT AFIN D’ÉVITER TOUT RISQUE D’INCENDIE OU D’ÉLECTROCUTION, NE PAS EXPOSER CET APPAREIL À LA PLUIE OU À L’HUMIDITÉ. NE PAS UTILISER LA FICHE D’ALIMENTATION POLARISÉE AVEC UNE PRISE DE CORDON DE RALLONGE OU AUTRE PRISE SAUF SI LES BROCHES PEUVENT ÊTRE ENTIÈREMENT INTRODUITES. NE PAS OUVRIR LE BOÎTIER, LEQUEL CONTIENT DES COMPOSANTS À...
Contenu La boîte* de votre nouveau moniteur NEC MultiSync contient : ® • Moniteur MultiSync LCD avec socle inclinable 1830 • Cordon d'alimentation • Câble d’interface vidéo • Manuel de l’utilisateur U S E R ' S M A N U A L MultiSync ®...
NOTA : Pour obtenir un adaptateur de câble Macintosh pour le MultiSync LCD 1830 appelez NEC-Mitsubishi Electronics Display of America, Inc. au (800) 820-1230. 3. Relie la 15 épingle mini D SUB de la vidéo signale du câble au connecteur “INPUT 1”...
Seite 28
Mise en marche rapide (suite) Figure C.1 Cordon d'alimentation Câble d’interface vidéo 1. Des câbles passent dedans à travers de trou. 2. Relie connecteur chaque. 3. Remplace connecteur de l’étui sur câbles passant à travers de upper ouvrant. Power Outlet AC-IN INPUT2 INPUT1...
Seite 29
Mise en marche rapide (suite) Marque Cache-câble Partie marquée Pour enlever le cache-câble: (1.Appuyer) 1. Appuyer sur la partie marquée 2. Faire glisser vers le haut 3. Enlever Appuyer Appuyer Couvercle de connecteur Pour enlever le couvercle : 1. Appuyer à la partie inférieure 2.
Seite 30
Mise en marche rapide (suite) T i l t Poigne et côtés de l’écran filtre sur vos mains et ajuste le tilt que désirai (Figure TS.1). Figure TS.1 Remove Contrôle Représenter Montage À préparer à d’alterner le montage des buts l’écran pour 1.
Commandes Les boutons de réglage OSM situés sur l’avant du moniteur fournissent les fonctions suivantes : Pour accéder au menu OSM, appuyez sur une des touches de commande À transformer signale de l’entrée, presser le INPUT 1/2 bouton. Menu principal Sous-menu Quitte les commandes OSM.
Seite 32
Commandes (suite) Réglage image SIMPLE Règle la dimension horizontale de l’image en augmentant ou en diminuant le format horizontal. Améliore la mise au point, la netteté et la stabilité de l’image en augmentant ou en diminuant la valeur Fin. RÉGLAGE AUTO Ajuste automatiquement les réglages SIMPLE et FIN.
Seite 33
Commandes (suite) Outils 2 LANGAGE : Les menus de l’OSM sont disponibles en sept langues. POSITION DE L’OSM : Vous pouvez choisir l’empmacement ou vous souhaitez que la fenêtre des commandes OSM apparaisse sur l’écran. En choisissant Position OSM, vous pouvez régler manuellement la position du menu de commande OSM : droite, haut ou bas.
Usage recommandé Consignes de sécurité et d’entretien POUR UN FONCTIONNEMENT OPTIMAL, PRIÈRE DE NOTER CE QUI SUIT POUR LE RÉGLAGE ET L'UTILISATION DU MONITEUR COULEUR MULTISYNC ® LCD : • NE PAS OUVRIR LE MONITEUR. Aucune pièce intérieure ne nécessite l'intervention de l'utilisateur, et l'ouverture ou la dépose des couvercles peut entraîner des risques de décharges électriques dangereuses ou d'autres risques.
Seite 35
Pour des informations plus détaillées sur l'établissement d'un environnement de travail sain, appeler NEC au (800) 820-1230, demander le service d’information par télécopieur NEC FastFacts au (800) 366-0476 et demander le document n 900108 ou écrire à...
60 Hz à 85 1152 x 864* @ 75Hz 1152 x 900* @ 66Hz NEC-Misubishi Electronics Display 1280 x 960* @ 60Hz to 75Hz recommande une résolution à 60 Hz 1280 x 1024 @ 60 Hz à 76 Hz ....pour des performances d’affichage optimales.
MultiSync a n’importe quel autre bras au baie de montage conforme VESA. Permet de monter le moniteur sur un mur ou un bras à l’aide de n’importe quel autre dispositif compatible. OSM Display Screen Copyright 2000 par NEC-Mitsubishi Electronics Display of America, Inc. LCD1830.wpc 11/29/00, 9:57 AM...
«fantôme» de cette image, il faut mettre le moniteur hors tension pendant une heure pour effacer l’image. NOTA : Tout comme dans le cas des écrans personnels, NEC-Mitsubishi Electronics Display recommande l’utilisation d’un économiseur d’énergie à...
Références • BBS (978) 742-8706 Le système de babillard électronique NEC-Mitsubishi Electronics Display of America, Inc. est un service électronique accessible avec votre système et un modem. Les paramètres de communication sont : 300/1200/2400/9600/ 1,4 k/28,8 k/33,6 k bps, pas de parité, 8 bits de données, 1 bit d'arrêt •...
à l ’autre. Par conséquent, l’adéquation d’un produit à un besoin ou une application spécifique doit être déterminée par le consommateur et n’est pas garantie par NMD-A. Pour connaître le nom du centre de service technique agréé NEC-Mitsubishi Electronics Display le plus proche, appeler NEC-Mitsubishi Electronics Display of America au 1-800-632-4662.
TCO’95 (C’est une traduction de portion Anglaise de TCO’95.) MultiSync LCD1830 Pour Noir la Modéle (LA-18S02-BK) Félicitations! Vous avez acheté un produit qui répond à la directive TCO’95. En choisissant ce produit conçu pour une utilisation professionnelle, vous contribuez aussi à la réduction des effets nuisibles sur l’environnement et aussi au développement continu de produits électroniques respectueux de...
Seite 42
TCO’95 (suite) de substances ignifuges. Ces dernières s’apparentent à un autre groupe de toxines environnementales, les PCB, qui sont suspectés de provoquer les mêmes effets néfastes, dont la modification de la reproduction chez les oiseaux piscivores et les mammifères, attribuable aux processus biocumulatifs*.
Seite 43
TCO’99 (C’est une traduction de portion Anglaise de TCO’99.) MultiSync LCD1830 Pour Blanche la Modéle (LA-18S02) Félicitations! Vous avez acheté un produit qui répond à la directive TCO’99. En choisissant ce produit conçu pour une utilisation professionnelle, vous contribuez aussi à la réduction des effets nuisibles sur l’environnement et aussi au développement continu de produits électroniques respectueux de...
TCO’99 (suite) 25 grammes ne contiennent pas de retardateurs de flame contenant du chlore ou du brome organiquement liés. Les retardateurs de flame sont autorisés dans les cartes à circuits imprimés étant donné qu’aucun substitut n’est encore disponible. Plomb** Le plomb peut être présent dans les tubes cathodiques, les écrans, les soudures et les condensateurs. Le plomb s’attaque au système nerveux et, à...
– EN 61000-3-3 – EN 55024 (IEC 61000-4-2) (IEC 61000-4-3) (IEC 61000-4-4) (IEC 61000-4-5) (IEC 61000-4-6) (IEC 61000-4-8) (IEC 61000-4-11) et porte le sigle NEC-Mitsubishi Electric Visual Systems Corporation 686-1, Nishioi Oi-Machi Ashigarakami-gun Kanagawa 258-8533, Japan LCD1830.wpc 11/29/00, 9:57 AM...
à condition que ces droits n'ont pas été directement délivrés à d'autres. Les produits de NEC-Mitsubishi Electronics Display of America dont il est question dans ce document sont garantis conformément aux termes de la déclaration de garantie limitée accompagnant chaque produit. Cependant, les performances réelles de chaque produit dépendent de facteurs tels que la configuration du système, les données du client...
C.S.A. C22.2 # 950. Informationen der FCC (Federal Communications Commission) 1. Verwenden Sie mit dem MultiSync LCD1830 (LA-18S02 and LA-18S02-BK) Farbmonitors die angeschlossenen und genannten Kabel, um keinerlei Interferenzen mit Radio- und Fernsehempfang zu verursachen. (1) Verwenden Sie bitte das mitgelieferte Netzkabel bzw. ein äquivalentes Kabel, um die FCC- Konformität sicherzustellen.
Lieferumfang Ihr neues MultiSync ® LCD Monitor-Paket* von NEC sollte den nachfolgenden Inhalt umfassen: • MultiSync LCD Monitor mit Schwenk-/Kipp-/Drehfuß MultiSync ® ™ 1830 • Netzkabel • Videosignalkabel • Benutzerhandbuch U S E R ' S M A N U A L MultiSync ®...
2. Für den PC: verbinden Sie die 15-Nadel kleiner D-ERSATZ des geeigneten Signal-Kabels zum Verbindungsstecker der Auslage-Karte in Ihrem System (Figure A.1). Ziehen Sie alle Schrauben fest. Für den Mac: verbinden Sie den MultiSync LCD1830™ Macintosh Kabel-Anpassungsvorrichtung zum Computer (Figure B.1). Befestigen Sie die 15-Nadel kleiner D-UNTER Ende des geeigneten Signal-Kabels zum MultiSync LCD1830 Macintosh Kabel-Anpassungsvorrichtung (Figure B.1).
Seite 50
Quick Start –fortsetzung Figure C.1 AC Power Cord Signal Cable 1. Kabel gehen durch in diesem loch vorbei. 2. Verbinden sie jeden verbindungsstecker. 3. Tausche Verbindungsstecker Schoner mit bestehenden durch einweihenden Ober Telegrammen aus. Treiben Sie ß Abflu AC-IN INPUT2 INPUT1 Zu Computer Power Switch...
Seite 51
Quick Start –fortsetzung Marque Telegramm Bedeckt Auszeichnenden Wie zu ausquartieren diesen Schoner. Gebiet 1. Auszeichnender Gebiet Schub (1. Schub ) 2. Gleite um den Rand zu up aus 3. Remove Schub Schub Verbindungsstecker-Decke Wie zu ausquartieren diesen Schoner. 1. Betreibe unter dem Rand 2.
Seite 52
Quick Start –fortsetzung Neigung Begreifen Sie beide Seiten des Monitor Bildschirmes mit Ihren Händen und stellt die Figure TS.1 Neigung ein wie gewünscht (Figure TS.1). Entfernen Sie Monitor, stehen Sie für das Besteigen Um den Monitor für Ersatz-Einbau Zwecke vorzubereiten: 1.
Bedienungselemente Mit den vorne am Monitor befindlichen OSM ™ - (On-Screen Manager)-Tasten werden die folgenden Funktionen ausgeführt : Um auf OSM Speisekarte zuzugreifen, drücken Sie keine der Kontrolle-Knöpf. ( Um Signal-Eingabe zu verändern, drücken Sie die EINGABE 1/2 Knopf. Hauptmenü Untermenü...
Seite 54
Bedienungselemente –fortsetzung Positionsregler LINKS / RECHTS Steuert die horizontale Bildposition innerhalb des LCD-Anzeigebereichs. UNTEN / OBEN Steuert die vertikale Bildposition innerhalb des LCD-Anzeigebereichs. AUTOM. EINST Stellt die horizontale und die vertikale Bildposition innerhalb des LCD- Anzeigebereichs automatisch ein. Bildanpassungsregler BILDPUNKTE Paßt die horizontale Bildgröß...
Seite 55
Bedienungselemente –fortsetzung SIGNAL PRIORITÄT: Zur Wahl des Verfahrens zur Erkennung des Videosignals, wenn zwei Rechner an den Monitor angeschlossen sind. KEINES: Der Monitor sucht nur im eingeschalteten Zustand den anderen Videoeingang. ERSTES SIGNAL: In dieser Stellung schaltet der Monitor automatisch nur dann auf den anderen Eingang um, wenn am ersten kein Signal mehr anliegt.
Seite 56
Bedienungselemente –fortsetzung Information GRAFIK MODUS: Liefert Information über die derzeitige Auflösung auf dem Bildschirm sowie technische Daten einschließlich der benutzten Voreinstellzeit sowie der horizontalen und vertikalen Frequenzen. MONITORINFORMATION: Zeigt Modell-und Seriennummern des Monitors. ™ Warnung OSM ermahnenden Speisezettel macht mit Ausgang EXIT davon. KEIN SIGNAL: Warnung,wenn kein Signal anliegt.
Empfehlungen für die Verwendung Vorsichtsmaßnahmen und Wartung UM DIE OPTIMALE LEISTUNGSFÄHIGKEIT IHRES MULTISYNC LCD FARBMONITORS ZU GEWÄHRLEISTEN, SOLLTEN SIE BEI DER AUFSTELLUNG UND VERWENDUNG IHRES GERÄTES DIE FOLGENDEN PUNKTE BEACHTEN • ÖFFNEN SIE DEN MONITOR NICHT. Im Inneren des Gerätes befinden sich keine Teile, die vom Benutzer selbst gewartet werden können.
Seite 58
• Verwenden Sie die Primärfarbe Blau nicht vor einem dunklen Hintergrund, da sie schlecht zu sehen wäre und aufgrund des unzureichenden Kontrasts zu einer Überanstrengung der Augen führen könnte Nähere Informationen über die Einrichtung einer gesunden Arbeitsumgebung erhalten Sie, wenn Sie NEC unter der Telefonnummer (800) 820-1230 bzw. NEC FastFacts ™...
66Hz 1280 x 960* 60Hz bis 75Hz Für optimale Darstellungsleitung des Monitors 1280 x 1024 @ 60 Hz bis 76 Hz ....und Farben empfiehlt NEC eine Auflösung bei 60 Hz Horiz.: 359 mm/14.1 Zoll Aktivanzeige Vert.: 287 mm/11.3 Zoll AC 100 V - 120 V/220–240 V @ 50/60Hz...
VESA-Montagearm oder Halter von Drittlieferanten montiert werden. So kann der Monitor unter Verwendung einer kompatiblen Montagevorrichtung eines Drittlieferanten an einer Wand oder an einem Tragarm montiert werden. OSM Display Screen Copyright 2000 by NEC-Mitsubishi Electronic Display of America, Inc. LCD1830.wpc 11/29/00, 9:57 AM...
”ghost wäre,” von diesen Bild-Überreste sollte der Monitor eine Stunde ausgemacht werden, um das Bild auszuradieren. HINWEIS: NEC-Mitsubishi Electronics Display empfiehlt, wie für alle persönlichen Anzeigegeräte, die regelmäßige Verwendung eines Screensavers, der sich einschaltet, wenn das angezeigte Bild länger unverändert bleibt.
Verweise • BBS (978) 742-8706 Das Remote Bulletin Board System von NEC-Mitsubishi Electronics Display ist ein elektronischer Service, den Sie mit Hilfe Ihres Systems und eines Modems nutzen können. Die Kommunikationsparameter lauten: 300/1200/2400/ 9600/14,4k/28,8k/33.6 k bps, keine Parität, 8 Datenbits, 1 Stopbit •...
Beschränkte Gewährleistung NEC-Mitsubishi Electronics Display of America, Inc. (nachstehend als „ NMD-A “ bezeichnet) garantiert hiermit, daß dieses Produkt keinerlei Material- und Verarbeitungsfehler aufweist, und verpflichtet sich unter den nachstehenden Bedingungen dazu, innerhalb eines Zeitraums von drei (3) Jahren nach dem Datum des ersten Erwerbs durch einen Verbraucher jedweden Teil des gegenständlichen Produkts, der sich als defekt erweist, (nach...
TCO’95 (Dieses ist eine Übersetzung von Englischer Portion TCO’95.) MultiSync LCD1830 Schwarzes Modell (LA-18S02-BK) Herzliche Gratulation! Sie haben gerade eines der unter TCO’95 zugelassenen und zertifizierten Produkte erworben. Damit steht Ihnen ein Produkt zur Verfügung, das für die gewerbliche Anwendung entwickelt wurde. Ihr Kauf hat außerdem dazu beigetragen, die Umweltbelastung zu reduzieren und die...
Seite 65
TCO’95 –fortsetzung bestehen. Diese sind verwandt mit einer weiteren Gruppe von Umweltgiften, den PCBs (polychlorierten Biphenylenen), die im Verdacht stehen, ähnlich schädlich zu sein und unter anderem aufgrund bioakkumulativer Prozesse* auch negative Auswirkungen auf die Vermehrung fischfressender Vögel und Säugetiere zu haben. Entflammungsverzögerer wurden auch im menschlichen Blut gefunden, und die Wissenschaftler fürchten, daß...
Seite 66
TCO’99 (Dieses ist eine Übersetzung von Englischer Portion TCO’99.) MultiSync LCD1830 Weißes Modell (LA-18S02) Herzliche Gratulation! Sie haben gerade eines der unter TCO’99 zugelassenen und zertifizierten Produkte erworben. Damit steht lhnen ein Produkt zur Verfügung, das für die gewerbliche Anwendung entwickelt wurde.
TCO’99 –fortsetzung bioakkumulativer Prozesse* auch negative Auswirkungen auf die Vermehrung fischfressender Vögel und Säugetiere zu haben. Entflammungsverzögerer wurden auch im menschlichen Blut gefunden, und die Wissenschaftler fürchten, daß sie Störungen der fetalen Entwicklung zur Folge haben könnten. TCO’99 verlangt, daß Plastikkomponenten, die mehr als 25 Gramm wiegen, keine Entflammungsverzögerer mit organisch gebundenem Chlor oder Brom enthalten dürfen.
Wir erklären hiermit, daß die obengenannte Ausrüstung den in den FCC-Bestimmungen enthaltenen technischen Standards entspricht. Windows ist ein eingetragenes Warenzeichen der Firma Microsoft Corporation. NEC ist ein eingetragenes Warenzeichen von NEC Corporation. ist ein in den U.S.A. eingetragenes Warenzeichen. Alle sonstigen Marken und Producktnamen sind NERGY Warenzeichen oder eingetragene Warenzeichen ihrer jeweiligen Inhaber.
NEC LCD Series PROPRIETARY NOTICE AND LIABILITY DISCLAIMER The information disclosed in this document, including all designs and related materials, is the valuable property of NEC- Mitsubishi Electronics Display of America and/or its licensors, as appropriate, reserve all patent, copyright and other proprietary rights to this document, including all design, manufacturing, reproduction, use and sales rights thereto, except to the extent said rights are expressly granted to others.
