5. Technical data

AC motor
Power
Operating mode
Idle speed n
0
Protection type
Stroke
Base area
Tilting range of table
Size of table
Length of saw blade
Max. cutting length at 90°
Max. cutting length at 45°
Weight
Wavelength of laser
Laser output
Load factor:
A load factor of S2 5 min (intermittent periodic duty)
means that you may operate the motor continuously
at its nominal power level (120 W) for no longer than
the time stipulated on the specifications label (5
minutes ON period). If you fail to observe this time
limit the motor will overheat. During the OFF period
the motor will cool again to its starting temperature.
6. Before putting the machine into
operation
6.1 General
All covers and safety devices have to be properly
fitted before the machine is switched on.
It must be possible for the blade to run freely.
When working with wood that has been
processed before, watch out for foreign bodies
such as nails or screws etc.
Before you actuate the On/Off switch, make sure
that the saw blade is correctly fitted and that the
machineʼs moving parts run smoothly.
Before you connect the machine to the power
supply, make sure the data on the rating plate is
the same as that for your mains.
6.2 Mounting the saw on a workbench Fig. 1
1. It is better to mount the saw on a solid wood
workbench rather than on a weak plywood stand
where vibrations and noise are certain to be a
14
11.12.2006 15:54 Uhr Seite 14
nuisance.
2. The tools and hardware needed to mount the
230-240V ~ 50Hz
saw on a work bench are not supplied with the
70/120 Watt
saw. Be sure to use equipment of at least the
S1/S2 5 min
following size:
400-1500 min -1
IP 20
Item
15 mm Hex screws M8
Gaskets Ø 8 mm
470 x 190 mm
Washers Ø 8 mm
-45°/0°/45°
Hex nuts M8
420 x 270 mm
127 mm
3. Use the provided assembly holes (23) to
50 mm
assemble the device. Do not tighten the screws
20 mm
too strongly. Leave sufficient play for the rubber
17 kg feet (24) to be able to absorb properly.
650 nm
< 1 mW

7. Installation

Important! Always pull out the power plug before
carrying out any maintenance or conversion work on
the fretsaw.
7.1 Fitting the saw blade guard (Fig. 3/4)
Fit the saw blade guard (11) using the Allen
screw (a) and the nut (b), as shown in Fig. 3.
Lock the saw blade guard (11) in position with the
holding screw (12), as shown in Fig. 4.
7.2 Changing the saw blade (Fig. 7/9)
Unlock the saw blade guard (11) as described in
7.1. Swing the saw blade guard (11) towards the
back. Pull the saw blade clamping lever (16) up in
order to release the tension from the saw blade
(20).
Undo the Allen screw (c) on the top saw blade
holder (17). Open the inspection flap (18). Undo
the Allen screw (d) on the bottom saw blade
holder (19). Pull the saw blade (20) out through
the table insert (15).
Fit the new saw blade by following the above
instructions in reverse.
The universal saw blade holders (17/19) permit
the use of both fretsaw blades and coping saw
blades.
Important! Always fit the saw blade with the
teeth facing in the direction of the sawing table
(14)!
Quantity
4
4
4
8
