ENGLISH

Daily use

Switching the hob ON/OFF
To switch the hob on, press the
button for approx. 2 seconds until the
cooking zone displays light up. To switch
off, press the same button until the displays
switch off. All the cooking zones are
deactivated. If the hob has been in use, the
residual heat indicator "H" remains lit until
the cooking zones have cooled down.
If within 10 seconds of switching on, no
function is selected, the hob switches off
automatically without press ON/OFF button.
Before use
Important: The induction cooking zones will
not switch on if pots and pans are not of the
correct dimensions.
Only use pots bearing the symbol
"INDUCTION SYSTEM".
Before switching the hob on, position the
pot on the desired cooking zone.
Existing pots and pans:
Use a magnet to check whether pots or
pans are suitable for use on the induction
hob: pots are unsuitable if they cannot be
magnetically detected.
1. Ensure pots have a smooth bottom,
otherwise they may scratch the hob's
glass ceramic surface. Check dishes.
2. Do not use empty pots on the hob. This
could result in damage to both the glass
ceramic surface and the bottom of the
pots.
3. Never place hot pots or pans on the
hob's control panel. This could result in
damage.
Recommended pot bottom widths
Ø Zone
210 mm
Flexi
145 mm
B
Ø Pot
150 - 210 mm
120 - 230x380 mm
100 - 145 mm
Switching on and adjusting cooking zones
Power indicator display
Selected cooking zone indication
Cooking zone positioning
Once the hob is switched on and the pan
is positioned on the chosen cooking zone,
select the zone using the corresponding
A
button (corresponding one slider
position) the display will show the selected
level.
With the Slider it is possible to select the
required power level, from min. 0 to max. 9,
or booster "P". To increase the power level,
select the level of power pressing the slider
area and adjusting to have a right level.
Each cooking zone has various power levels,
adjustable with the dedicated slider, going
from "1": min. power, to "9": max. power.
All cooking zones have a fast boil function
(Booster), shown on the display with the
letter "P".
Fast boil function (Booster)
This function makes it possible to exploit the
hob's maximum power (for example to bring
water to the boil very quickly).
To activate the function, press the button
"P". "P" appears on the display. After 10
minutes' use of the booster function, the
appliance automatically sets the zone to
level 9.
Timer
The timer can be used to set cooking time
for a maximum of 99 minutes for all cooking
zones.
7
