7. Installation of the
GB
tail servo
A
Attention important!
In order to achieve best possible effect
of the gyro, the servo lever (12) and the
control rods (13) must be in a 90-degree
angle to one another (neutral position).
The installation of the tail servo (11) and
the tail rotor are normally precisely set
12
out in the documents of the model
11
helicopter.
13
The distance (A) is based on the model
size and is normally stated in the
documents of the model helicopter.
Observe an absolutely smooth and at
the same time free-of-clearance control
of the tail rotor. Because only if the
smallest of servo deflections trigger a
control reaction on the model, the gyro
can work to its optimum.
12
