GAIN CONTROL Menu
MANUAL: Individual menu options are manually
AUTO:
Notes:
• Press the
• To choose a menu option:
• To go to the next menu:
* Auto Gain Control function
• The Auto Gain Control adjusts contrast and black
level based on the brightest color of the image
displayed. If you are not using the Adjustment Pattern
it is necessary to have an area of 5 mm x 5 mm of
white displayed, and if not adjustments may not be
possible. (In such case, [OUT OF ADJUST] will
appear and setting values remain unchanged.)
• If the signal coming from the computer is composite
sync or sync on green, automatic adjustment cannot
be performed. Please perform manual adjustment
instead.
BLACK LEVEL
Total screen brightness can be adjusted while watching
the color pattern. (
CONTRAST
While watching the color pattern, adjustments can be
made so that all graduations appear. (
Downloaded from www.Manualslib.com
Adjusting the screen display (when using an analog signal)
adjusted.
Every menu option is automatically adjusted
using the Auto Gain Control* function,
button to select [AUTO].
SELECT button
MENU button
buttons)
Color pattern
buttons)
manuals search engine
WHITE BALANCE Menu
Notes:
• On settings other than [STD] not all graduations can
be displayed. To display all graduations, set to [STD].
• Use the buttons to select [COOL], [·], [STD], [·],
[WARM] or [USER].
• Selecting USER will display the setting values for [R-
CONTRAST], [G-CONTRAST] and [B-CONTRAST],
in order to make fine adjustments.
• Use the SELECT button to select [R-CONTRAST],
[G-CONTRAST] and [B-CONTRAST].
• To go to the next menu:
COOL . . . . . Color tone bluer than standard
• . . . . . . . Color tone slightly bluer than standard
STD . . . . . . . Color tone standard setting
• . . . . . . . Color tone slightly redder than standard
WARM . . . . . Color tone redder than standard
USER
R-CONTRAST . . . button for blue-green
button for red
G-CONTRAST . . . button for purple
button for green
B-CONTRAST . . . button for yellow
button for blue
21
