Installation Summary - Indoor Unit - INVENTOR P9VI32-09WF Installationshandbuch

Installation Summary - Indoor Unit

1
12cm
(4.75in)
2.3m (90.55in)
Select Installation Location
3
Attach Mounting Plate
(Page 12)
Page 8
ƒ „
15cm (5.9in)
(Page 11)
2
12cm
(4.75in)
4
Determine Wall Hole Position
(Page 12)
Drill Wall Hole
(Page 12)
2
