MOUNTING PLATE DIMENSIONS
Different models have different mounting plates.
In order to ensure that you have ample room to
mount the indoor unit, the diagrams to the right
show different types of mounting plates along
with the following dimensions:
Width of mounting plate
•
Height of mounting plate
•
Width of indoor unit relative to plate
•
Height of indoor unit relative to plate
•
Recommended position of wall hole (both
•
to the left and right of mounting plate)
Relative distances between screw holes
•
Correct orientation of Mounting Plate
Outdoor
Indoor unit outline
318mm(12.5in)
pipe hole
65mm
φ
（2.56 in）
102mm(4in)
717mm(28.2in)
Model A
Indoor unit outline
406.4mm(16in)
pipe hole
65mm
φ
（2.56 in）
102mm(4in)
805mm(31.7in)
Model B
Indoor unit outline
pipe hole
65mm
φ
（2.56 in）
219mm(8.62in)
Indoor unit outline
pipe hole
65mm
φ
（2.56 in）
174mm
(6.85in)
1106mm(43.5in)
NOTE: When the gas side connective pipe is
16mm(5/8in) or more, the wall hole should
Φ
be 90mm(3.54in).
409mm(16.1in)
249mm(9.8in)
pipe hole
65mm
φ
（2.56 in）
153mm(6in)
452.7mm(17.8in)
249mm(9.8in)
pipe hole
65mm
φ
（2.56 in）
153mm(6in)
482mm(19in)
439mm(17.28in) 262mm(10.31in)
132mm
(5.20in)
964mm(37.9in)
Model C
599mm(23.6in)
558mm(21.97in) 320mm(12.60in)
pipe hole
130mm
65mm
φ
(5.12in)
（2.56 in）
Model D
