IKAR HWDB 2 Prüfbuch Und Gebrauchsanleitung Seite 14

Instructions for the correct
assembly of the special swivel
3.
1.
2.
Press the locking pin and tighten
by turning clockwise, until the ball
engages with a '
6.
The shoulder straps should now
be tight in the swivel assembly
and the device will sit correctly.l
1.
Hold the rear 'D' ring plate and
pull the D-ring to create a loop
4.
3.Klick!
Pull the bottom webbing shoulder
straps back through the
click '. swivel assembly first.
7.
The device is attached over the
D-ring, to give optimum access
to the D-ring in a rescue scenario.
ENGLISH
14
2.
Place the special swivel assembly over
the D-ring and push thelocking pin
behind the webbing loops.
5.
Now pull the top webbing shoulder
back through the swivel assembly.
special rotator
8.
opened
bolt
ball lock
ball lock pin
thread
