3.3.10

Monitor mounting

Fig. 14: Monitor mounting
3.3.11

Drawer cabinet

Fig. 15: Drawer cabinet
29.05.2019
The pivoting material rail (Fig. 13/2) is used as a mount for grab
containers and is positioned in the assembly workstation using the
swivel arm (Fig. 13/1).
Further information:
Ä Technical instructions for Easywork, chapter "Material rail"
n
The monitor mounting (Fig. 14) is used to fasten and position moni-
tors.
The monitor mounting is height-adjustable and tiltable.
Further information:
Ä Technical instructions for Easywork, chapter "Monitor
n
mounting"
The drawer cabinet (Fig. 15) is used a storage space, e.g. for tools
and other aids.
The drawer cabinet is available in different versions; with one, two
or three drawers.
Further information:
Ä Technical instructions for Easywork, chapter "Drawer
n
cabinet"
Assembly workstation RK Easywork
Set-up and function
Optional modules > Drawer cabinet
85
