Runner profile with carriage
Fig. 28: Runner profile with carriage
Monitor mounting
Fig. 29: Monitor mounting
Pivoting material rail
29.05.2019
Runner profile with carriage (a = left/b = right)
F
zmax a
M
ymax a
F
zmax b
M
ymax b
Monitor mounting
F
max
Fig. 30: Pivoting material rail
A with a fixed material rail
B with three tiltable material rails
Pivoting material rail
F (Fig. 30/A)
max
F (Fig. 30/B)
max
Assembly workstation RK Easywork
Technical data
800 N
20 Nm
800 N
20 Nm
15 kg
10 kg
20 kg
Load data
