RK Rose+Krieger RK Easywork Betriebsanleitung Seite 102

Technical data
Load data
Table
Fig. 24: Table
Material tray level with steel swivel
Fig. 25: Material tray level with steel
swivel
Material tray level with angle
adjustment
Fig. 26: Material tray level with angle
adjustment
Mounting rail
Fig. 27: Mounting rail
102
Table (a = left/b = right)
F
zmax a
M
ymax a
F
zmax b
M
ymax b
Material tray level with steel swivel (a = left/b = right)
F
zmax a
M
ymax a
F
zmax b
M
ymax b
Material tray level with angle adjustment (a = left/b = right)
F
zmax a
M
ymax a
F
zmax b
M
ymax b
Mounting rail with steel swivel (a = left/b = right)
F
zmax a
M
ymax a
F
zmax b
M
ymax b
Assembly workstation RK Easywork
2000 N
200 Nm
2000 N
200 Nm
1600 N
60 Nm
1600 N
60 Nm
2000 N
100 Nm
2000 N
100 Nm
1500 N
20 Nm
1500 N
20 Nm
