Moving components (optional
modules)
Falling components (optional
modules)
Loss of stability
29.05.2019
CAUTION!
Risk of crushing and impacts due to moving com-
ponents!
Reaching into or standing in the range of moving
optional modules (e.g. pivoting monitor mounting, piv-
oting material rail or pivoting material tray level) can
cause hand and head injuries.
– Do not reach into the range of the pivot arm/joint
when positioning the monitor mounting or material
rail.
– When setting the angle of inclination of the mate-
rial tray level, proceed carefully and do not reach
between the portal and the material tray level.
Danger zones:
n Risk of impacts from pivoting monitor mounting and material
rail.
n Risk of crushing between the portal and the material tray level.
CAUTION!
Risk of crushing and impacts from falling optional
modules!
High pressure loads and torsional stresses on the indi-
vidual optional modules can cause them to fall and
cause injuries.
– Never exceed the pressure loads or torsional
stresses defined by RK Rose+Krieger GmbH in
chapter
WARNING!
Risk of injury as a result of a loss of stability!
In the event of a loss of stability due to an unsuitable
surface, lateral forces or missing safeguards, the
assembly workstation may topple over. This can lead
to injuries and property damage.
– Only ever set up the assembly workstation on an
even substrate with sufficient load-bearing
capacity.
– Take into account any possible lateral forces and
install additional safeguards (e.g. screw the feet to
the substrate).
– Check the entire assembly workstation with user's
components to make sure it is sufficiently stable. In
case of doubt contact RK Rose+Krieger GmbH.
Assembly workstation RK Easywork
Residual risks > Mechanical hazards
Ä Chapter 8 "Technical data" on page 98.
