Structural layout
16 15
1
2
3
4
1 Cable strain relief
2 Power supply cord
3 Guide rod
4 Cable hook
5 Pad holder
6 Transport wheels
7 Bumper wheel / Swivel caster
8 Shell handle (for transport)
9 Motor ventilation
10 Adjusting lever to tilt the guide bar
11 Machine casing
12 Safety switch
13 Right operating lever (motor ON/OFF)
14 Handle bar
15 Mains plug display (plug inserted)
16 Key for electrical dispensing unit
17 Left operating lever (motor ON/OFF)
