DMX operation

Setting the number of DMX channels and the DMX starting address
For operation with a controller with DMX512 protocol, the device is equipped with 9 control channels.
However, it can also be switched to a mode with 2, 4, 5 or 6 channels if different functions are required. To
be able to operate the device with a DMX controller, the DMX starting address must be set for the first DMX
channel. The starting address depends upon which DMX controller is being used. Please refer to the
controller's documentation.
1 Press the UP or DOWN button so many times until Addr is indicated in the display. Confirm with the
ENTER button. Use the buttons UP and DOWN to select the desired DMX address. Confirm with the
ENTER button again.
2 Press the UP or DOWN button so many times until Chnd is indicated in the display. The display
indicates 2 CH (2 DMX channels), 4 CH (4 DMX channels), 5 CH (5 DMX channels), 6 CH (6 DMX
channels) or 9 CH (9 DMX channels). Use the buttons UP and DOWN to select the desired number of
DMX channels. Confirm with the ENTER button.
3 A dot will be flashing when DMX signals are being received.
Note: Please make sure that you do not have any overlapping channels in order to control each device
correctly and independently from any other fixture on the DMX chain. If several devices are addressed
similarly, they will work synchronically.
Functions in 2-channel mode
Channel
CH 1
CH 2
Functions in 4-channel mode
Channel
CH 1
CH 2
CH 3
CH 4
Function
000 – 005
006 – 017
018 – 029
030 – 041
042 – 053
054 – 065
066 – 077
078 – 089
090 – 101
Color selection
102 – 113
114 – 125
126 – 137
138 – 149
150 – 161
162 – 173
174 – 185
186 – 220
221 – 255
Dimmer 000 – 255
Function
Dimmer red 000 – 255
Dimmer green 000 – 255
Dimmer blue 000 – 255
Dimmer white 000 – 255
Value Details
No function
Red
Amber
Warm yellow
Yellow
Green
Turquoise
Cyan
Blue
Lavender
Purple
Magenta
Pink
Warm white
White
Cold white
Color change slow > fast
Color fade slow > fast
Master dimmer 0-100 %
Value Details
Dimmer 0-100 %
Dimmer 0-100 %
Dimmer 0-100 %
Dimmer 0-100 %
