- First connect the red clamp to the positive terminal on the
vehicle battery.
- Then connect the black clamp to a non-movable metal
part of the engine; do not connect the clamp to the
negative terminal on the battery.
WARNING: DANGER!
Connect the mounting socket (Fig. A-1) to the starter's
12V or 24V power supply, checking the voltage required
for the vehicle to be started, and only after being
absolutely certain that the clamps have been connected
to the battery polarities correctly.
- Connect the mounting socket following the instructions
above.
- Turn the ignition switch or key of the vehicle or boat to ON.
Wait about one minute. Turn the vehicle ignition switch or
key to the start position for no more than 5÷6 seconds. If
the vehicle or boat does not start, wait at least 3 minutes
before trying again.
Warning: Do not allow the black and red clamps
to come into contact with each other or to touch
a common conductor.
- Whilst the engine is running, disconnect the mounting
socket from the starter and the clamps from the vehicle in
the exact order seen below:
1. the mounting socket.
2. the black (negative) clamp.
3. the red (positive) clamp.
- Return the clamps to their housing on the starter.
It is highly recommended to recharge the starter as
soon as possible!
Using the starter as a 12V power supply unit by means of
the cigar-lighter type socket (Fig. A-4).
WARNING! 12V OUTPUT ONLY!
In case of overload the re-settable safety switch
will trip. To restore operation, remove the cause
of overload and press the button shown in Fig.A-2.
- Take the cover off the cigar-lighter type socket (Fig. A-4).
- Insert the cigar-lighter plug of the device to be powered
into the socket (Fig. A-4).
Recharging using a 230V AC power supply
Important! To protect the battery and lengthen
its working life, charge it for 12 hours before
using it for the first time, then after every time it
is used and, in any case, at least every 3 months.
It is possible to recharge the unit using the 230V AC power
adapter supplied. We recommend keeping the battery fully
charged at all times. A low charge level could shorten the life
of the battery. Bear in mind that the time needed to recharge
the battery depends on the number of times it has been
used. It is possible to check whether the battery level is low
by pressing the red button (Fig. A-5).
The voltmeter (Fig. A-3) will indicate the battery charge level.
The green area of the voltmeter indicates that the battery is
charged.
Recharging
1- Connect the free starter plug at POSITION 12V, making
sure that the starter clamps are positioned in the relative
pocket and insulated from each other.
2- Insert the car cigarette lighter plug supplied with the
battery charger into the starter outlet (Fig. A-4).
3- Insert the battery charger plug into a 230 V socket.
4- Allow the starter to recharge for as long as necessary
(refer to the battery charger user manual).
5- When charging is finished remove the battery charger
and disconnect the free starter plug from POSITION 12V.
Pb

DISPOSING OF THE BATTERY

When the starter battery is completely run down it should
be taken to a re-cycling depot. In some countries this is
mandatory. Contact the local special refuse authority for
information on recycling.
WARNING: Do not burn the battery to dispose of it. This
could cause an explosion. Before disposing of the battery,
apply insulating tape to the bare terminals to prevent
shorting. Do not expose the battery to intense heat or fire as
this could cause an explosion.
STARTER SPECIFICATIONS "4824"
Type of battery:
- rechargeable factory-sealed 12V acid-lead batteries.
Battery capacity:
- 40Ah.
Output current @ 24V:
- 2200A peak current;
- 800A starter current.
Output current @ 12V:
- 4400A peak current;
- 1600A starter current.
Copper cables:
- PVC insulated 16mm
Cable length:
- 190cm.
Output socket:
- 12V DC / max. current 10A.
General features:
- re-settable safety switch for output overload;
- automatic charging level reset switch;
- "cigar-lighter" type socket, 12V DC.
Weight:
- 24kg.
Standard accessories:
- T-CHARGE 12 Power supply / Battery charger (Fig. B).
STARTER SPECIFICATIONS "6824"
Type of battery:
- rechargeable factory-sealed 12V acid-lead batteries.
Battery capacity:
- 40Ah - 80Ah.
Output current @ 24V:
- 3000A peak current;
- 1000A starter current.
Output current @ 12V:
- 6000A peak current;
- 2000A starter current.
Copper cables:
- PVC insulated 25mm
Cable length:
- 220cm.
Output socket:
- 12V DC / max. current 10A.
General features:
- re-settable safety switch for output overload;
- automatic charging level reset switch;
- "cigar-lighter" type socket, 12V DC.
Weight:
- 39kg.
Standard accessories:
- T-CHARGE 12 Power supply / Battery charger (Fig. B).
