The Front Panel at a Glance

1
4
2
Display
1
Power ON/OFF Switch
2
Measurement functions
3
Math Operations
4
State Store/Recall, Utility Menu
5
Data Log, View
6
N O T E
2
3 6
For a complete list of all keypad functions and descriptions, please refer to
Chapter 1, "Getting Started Tutorial" in the 34450A User's Guide.
10 7 9
5 8
Auto range and Manual range
7
Resolution, Measurement Speed
8
SHIFT (selects blue shifted keys) and Local Key
9
Secondary Display Key
10
Input Terminals
11
11
34450A Quick Start Guide
