7.1 Service documentation

Service documentation is available at www.product-
selection.grundfos.com.
If you have any questions, please contact the
nearest Grundfos company or service workshop.

7.2 Maintenance

The lifting station does not require any special
maintenance, but we recommend that you check
operation and pipe connections at least once a year.
Change the carbon filter once a year.
See section 7.4 Service instructions.

7.3 Adjustment of run time

The default setting ensures proper operation in most
pipework. If the pipework is particularly long or short,
it may be necessary to adjust the run time.
For a guide to adjusting the run time, see
www.product-selection.grundfos.com.

7.4 Service instructions

Thanks to the product design, service is easy in case
of malfunction or blocked pump.
Digits in the following sections refer to the pictures in
the appendix at the end of this booklet.
Warning
Before carrying out any service work,
remove the fuse, pull out the plug, or
switch off the power supply. Make sure
that the power supply cannot be
accidentally switched on.
All rotating parts must have stopped
moving.
The product must only be serviced by
trained service personnel.
Impeller/grinder stuck
1.1 Disconnect the power supply.
1.2 Unscrew the plug in the cover.
1.3 Insert a screwdriver (min. 110 mm) through the
plug hole and into the slot of the shaft end.
Turn the shaft right and left to free the impeller/
grinder from dirt.
1.4 Fit the plug, and switch on the power supply to
check if the impeller/grinder can rotate freely.
Operation by means of a power drill
2.1 If the product cannot be operated by electrical
power, disconnect the power supply and empty
the toilet and tank by means of a power drill.
Pressure switch pipe blocked
The pressure switch unit can be removed
Note
separately.
3.1 If the water level in the tank is above the motor
flange, disconnect the power supply and drain
the tank by means of the drain hose
(accessory).
3.2 Unscrew the cover.
3.3 Pull out the complete pressure switch.
3.4 Check and clean the pressure switch pipe.
Make sure that the little tube in the top of
Caution
the pipe did not become blocked when you
cleaned the pipe!
Lubricate the sealing area of the pressure
Note
switch for easier fitting.
Foreign body in tank
If the water level in the tank is above the motor
flange, disconnect the power supply and drain the
tank by means of the drain hose (accessory).
Unscrew the cover. See 3.2.
4.1 Remove the four screws of the motor flange.
4.2 Lift the motor flange to reduce the compression
of the O-ring. Insert a screwdriver into the notch
underneath the power supply cable and press it
down.
4.3 Lift out the complete motor-pump unit by the
handles.
Note
Lift the unit vertically before tilting it!
4.4 Check and clean the tank and impeller/grinder.
Warning
Beware of the sharp edges on the grinder.
Wear protective gloves.
Carbon filter
5. Replace the carbon filter once a year to ensure
sufficient filter function.
Instead of using a carbon filter, Sololift can
also be vented through a venting pipe. In
Note
this case a venting valve is needed.
Product number: 98059587.
