f) Off
MODE
Press the button alternatively un-
til OFF appears on the screen. The unit
is turned off and the word OFF, the am-
bient temperature, the day of the week
and the time are displayed permanently
on the thermostat display (Fig. 8).
OFF
3
DISPLAY WHEN THE UNIT
IS FULLY OFF
Fig. 8
g) Ventilation only
This operating mode is available in the
OFF mode by pressing the
ton, which selects the fan speed.
OFF
3
h) °C/°F scale
To change the temperature degree
scale, press the
multaneously.
2.- Fan
When the button is pressed, the Ad-
just mode is entered for 5 seconds. The fan
symbol is flashing. Pressing de
button, you adjust the fan speeds (
the fan regulation: automatic (AUTO) or in
continuous operation (AUTO disappear).
When the fan is set automatic (AUTO), it
will operate automatically the fan in
acordance with the compressor or heating
sources. Example:
- Automatic high speed
AUTO
- Fixed low speed
- You can configurate the thermostat with
only one speed (micro-switch nº 6 to ON)
3.- Day/night selection
By pressing the button you can se-
lect different temperature settings for the day
and night periods (in each one of the oper-
ating modes).
Once the thermostat is installed, the
symbol is displayed, indicating that the tem-
perature settings selected is for the day
period (comfort). Pressing the
ton displays the
the temperature settings is for the night pe-
riod.
Whenever this button is pressed the tem-
perature settings are alternated, in both day
and night
4.- Unoccupied selection
Pressing the
ond selects the unoccupied temperature
setting. Pressing the
selects the desired temperature. If the
°C
button is pressed in AUTO mode, the cool
or heat set points in unoccupied mode are
displayed alternatively.
If while in the adjust mode the
ton is pressed, the temperature setting is
replaced by number 0, indicating the number
of days the unoccupied mode should last.
The and
decrease the number of unoccupied days.
If left at 0, this mode is maintained indefi-
nitely; but if a number of days beyond 0 is
but-
programmed, the
out the unoccupied period, indicating its
temporary nature. Once the unoccupied
period has concluded, the thermostat will
switch over to the day period (confort), ex-
cept when the air conditioning mode is
AUTO PROG, in which case the occupa-
°C tion mode will be the mode indicated by the
time schedule profile.
To exit the unoccupied option, just press the
button.
5.- Reading outdoor temperature
Pressing the
door temperature for 5 seconds.
6.- Ambient temperature remote sensor
option
buttons si-
The DPC-1 thermostat is designed to ac-
cept a remote sensor for controlling the
ambient temperature of a room other than
the one the DPC-1 thermostat is located
in.
These are three remote sensor options:
- RS1, remote probe. Connected to the in-
) and
ner connecting strip of the thermostat,
terminals RS1-RS2. Configure as S2.
- DS1, duct probe. Connected to the inner
connecting strip of the thermostat, termi-
nals RS1-RS2. Configure as S3.
- AS1, average digital remote probe. Con-
nected to the inner connecting strip of the
thermostat, terminals R, B and X1.
Configure as S5, S6, S7 or S8, depend-
ing upon number of probes installed.
7.- Graphic information
The display provides constant information
on: ambient temperature, operating mode,
day/night period and fan operation. To have
acces to information on the temperature set
points press, just once, one of the tempera-
ture setting buttons. This will give us, on
screen and for 5 seconds, the temperature
set point established for the operating
mode that is visible on screen at that mo-
ment.
but-

Programming menu

symbol, indicating that
If the
Mode , only the symbols of the different pa-
rameters that can be programmed are dis-
played on screen:
-
periods.
-
button for over 1 sec-
-
or button
MODE
-
but-
PROG
-
buttons increase and
-
icon flashes through-
The active or selectable option will flash.
The initial option is setting the clock.
button displays the out-
The active buttons are:
The display will come back to Normal mode
if no button have been pushed during 30
seconds.
1- Clock setting
Allows setting the day of the week, hour
and minutes.
GB
button is pressed in Normal
PROG
Clock setting (day of the week, hours
and minutes).
Fan setting.
Selection of schedule
0h 2 4 6 8 10 12 14 16 18 20 22 24
profiles. A schedule profile accepts
only Comfort and Economy (Day and
Night) periods. If pin 2 of the micro-
switch is set to OFF, this option is
not displayed.
Select temperature setting for heat-
ing and cooling mode in Comfort
(Day) period .
Select temperature setting for heat-
ing or cooling mode in Economy
(Night) Mode.
Select temperature setting for heat-
ing and cooling in Unoccupied Mo-
de .
0h 2 4 6 8 10 12 14 16 18 20 22 24
- Allow selecting the active option.
- Allow changing the selection.
- Selects the active option.
- Exits the Programming menu ,
switching the thermostat in Normal
Mode.
