3. Getting Started

Installing the Software

The software that is included with your instrument must be installed before
plugging the USB cable into the computer. The software installs the required
USB drivers for the instrument and application.
1.
Insert the CD into the CD drive. If the CD does not autorun, double-click
the Setup.exe file on the CD.
2.
The setup program guides you through the rest of the installation
process. Follow the instructions on each setup screen to complete the
installation. When finished, remove the CD and store in a safe location.

Charging the Battery

Connect the USB cable to the RM200QC and your computer's USB port. A
battery charging screen momentarily appears. For the first time connection, a
language selection screen also appears. Refer to the Initial Startup section on
the following page for first time operation.
Note: Some computers have low power USB ports which are typically located
at the front. It is recommended that RM200QC is ONLY connected to high
power ports.
During charging, the instrument switches on and indicates charging with a
"lightning bolt" in the battery icon. The RM200QC will not power off while
plugged into the computer USB port. A full charge from empty will take 6
hours connected to a computer USB port.

Powering On and Off (battery operation only)

Turn the instrument on by pressing and releasing the Power button.
Power button
RM200QC
