Connector Panel

Notes
1. An RGBS, YPbPr or VGA
2. An DVI, RGBS or YPbPr
3. The ND-OS connector allows
installed via the SERIAL connector.
4. The 5V/1A DC output is a protected Auxiliary
A video printer must be connected to the VGA/RGBS connector or the S-VIDEO connector.
5.
It may not be connected to the DVI-I/RGBS connector

Electrical Symbols

Equipotentiality: connector to other equipment (earth equipotential)
This symbol appears next to the display's potential equalization connector. (ground post)
Open (Off) Switch:
This symbol appears on the open, or off, side of the display's rocker switch.
Closed (On) Switch:
This symbol appears on the closed, or on, side of the display's rocker switch.
Alternating Current
Direct Current
signal may be applied via the VGA/RGBS connector.
signal may be applied via the DVI-I/RGBS connector.
BIOS upgrades to be installed rapidly.
connection.
BIOS upgrades may also be
See page 16 for details.
