Replacing the fuse

If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
1 Disconnect the device from power and allow it to cool.
2 Open the fuse holder of the mains connection with a fitting screwdriver.
3 Remove the old fuse from the fuse holder and replace it with a new fuse.
4 Carefully push the fuse holder back into its position before reapplying power.

PROTECTING THE ENVIRONMENT

Disposal of old equipment
When to be definitively put out of operation, take the product to a local recycling plant for a
disposal which is not harmful to the environment. Devices marked with this symbol must not be
disposed of as household waste. Contact your retailer or local authorities for more information.
Remove any inserted batteries and dispose of them separately from the product.
You as the end user are required by law (Battery Ordinance) to return all used batteries/
rechargeable batteries. Disposing of them in the household waste is prohibited. You may return
your used batteries free of charge to collection points in your municipality and anywhere where
batteries/rechargeable batteries are sold. By disposing of used devices and batteries correctly,
you contribute to the protection of the environment.

TECHNICAL SPECIFICATIONS

Model no:
Power supply:
Power consumption:
Protection class:
Protection grade:
LED:
Flash rate:
DMX channels:
DMX input:
DMX output:
QuickDMX connection:
Power connection:
Power output:
Sound-control:
Cooling fan:
Control:
Fuse:
Beam angle:
Case color:
Width:
Height:
Depth:
Weight:
Remote control
Battery:
42109630
Spot 4 x high-power 8 W 4in1 QCL RGBW (homogenous color mix)
Strobe effect 4 x high-power 1 W CW
QuickDMX via 5-pin XLR (M)
mounting version
Mains input IEC connector (M) mounting version Power supply cord with safety
1 x IEC connector (F) mounting version
Black
1 x Button cell 3.0 V CR2025 lithium manganese built-in
32/34
100-240 V AC, 50/60 Hz
80 W
I
IP20
0 - 20 Hz
3; 4; 8; 21
3-pin XLR (M) mounting version
3-pin XLR (F) mounting version
plug (provided)
via built-in microphone
No, cooling by convection
IR remote control
DMX
Stand-alone
QuickDMX
Sound to light via Microphone
T 1 A, 250V
9°
60.5 cm
23 cm
14 cm
4.85 kg
42109635
Quick DMX via USB
White
00126056, Version 1.0
