TITANIUM 400 AC/DC
The Balance (%T_AC):
during the positive wave, the oxidation is broken. During the negative wave, the electrode cools and the parts are welded, there is penetration. By
modifying the ratio between 2 alternatives through the balance adjustment, you choose either cleaning or penetration (the default value is 30%).
20%: Max. penetration
The frequency (AC Hz):
the frequency allows you to adjust the concentration of the arc. The higher the frequency, the more concentrated the arc. The lower the frequency
the wider the arc will be.
High Low
TIG AC - Pulse
This pulsed current welding mode is a combination of high current pulses (I, welding pulse) and low current pulses (I_Cold, part cooling pulse). This
pulse mode allows to assemble pieces while while keeping the machine cooler.
Example :
The I welding current is set to a 100A and % (I_cold) = 50%, thus a Cold current of = 50% x 100A = 50A.
F(Hz) is set to 2Hz, the signal period will be 1/2Hz = 500ms -> every 250ms, one pulse at 100A then another at 50A will follow one another.
Adjustable
Settings Designation
settings
Pre-gas 0 - 60 sec.
Starting current 10 - 200%
Starting time 0 - 10 sec.
Rising current 0 - 60 sec.
Welding current 3 - 400A
Wave shape
Cold current/Back-
20 - 80%
ground current)
Cold weather 20 - 80%
Frequency
0.1 - 2500 Hz
of pulsation
Downslope 0 - 60 sec.
End current 10 - 200%
End duration 0 - 10 sec.
Post-gas 0 - 60 sec.
AC wave shape
36
50% 60%: Max. pickling
Description & advice
Time to purge the torch and to protect the area with gas before ignition
This starting bearing current is a phase before the current rise ramp.
Current rise ramp.
Welding current.
Waveform of the pulsed part.
Second welding current known as "cold" welding current
Time balance of the warm current (I) of the pulsation
Pulse frequency
Downslope current.
This stopping stop current is a phase after the current descent ramp.
Duration for which gas is released after the arc has stopped. It protects the weld pool
and the electrode against oxidisation when the metal is cooling down.
AC waveform.
EN
Frequency of
welding
Penetration and clea-
ning (%)
TIG AC - MIX
This method of alternating current welding is used to weld aluminium and its thick alloys. It mixes DC periods whist welding in order to increase the
energy flow to the workpiece. The final goal is to accelerate the work advance and therefore productivity on aluminium assemblies. This mode pro-
duces less pickling so it is necessary to work on clean sheets.
Settings Designation
Pre-gas
Starting current
Starting time
Rising current
Welding current
Évanouisseur
End current
End duration
Post-gas
AC wave shape
Frequency
welding
Penetration and clea-
ning (%)
AC time
DC time
THE TIG DC or AC TIG POINTAGE
SPOT (TIG DC or AC)
This welding mode allows the pre-assembly of the parts before welding. Scoring can be manual by trigger or delayed with a predefined scoring delay.
This pointing time allows a better reproducibility and the realization of non-oxidized point (accessible in the advanced menu).
TITANIUM 400 AC/DC
20 - 300 Hz Frequency of polarity reversals welding - pickling
20 - 60% Percentage of the welding period dedicated to pickling (default 30-35%)
Adjustable
Description & advice
settings
0 - 60 sec. Time to purge the torch and to protect the area with gas before ignition
10 - 200 %
This starting bearing current is a phase before the current rise ramp.
0 - 10 sec.
0 - 60 sec. Current rise ramp.
3 - 400 A Welding current.
0 - 60 sec. Down slope current.
10 - 200 %
This stopping stop current is a phase after the current descent ramp.
0 - 10 sec.
Duration for which gas is released after the arc has stopped. It protects the weld pool
0 - 60 sec.
and the electrode against oxidisation when the metal is cooling down.
AC waveform.
20 - 300 Hz Frequency of polarity reversals welding - pickling
20 - 60 % Percentage of the welding period dedicated to pickling (default 30-35%)
0 - 10 sec. Welding time in AC TIG welding
0 - 10 sec. Welding time in DC TIG welding
EN
