Keep the battery charger clean. Contamina-
tion can lead to danger of an electric shock.
Before each use, check the battery charger,
cable and plug. If damage is detected, do
not use the battery charger. Never open the
battery charger yourself. Have repairs per-
formed only by a qualified technician and
only using original spare parts. Damaged
battery chargers, cables and plugs increase
the risk of an electric shock.
Do not operate the battery charger on easily
inflammable surfaces (e.g., paper, textiles,
etc.) or surroundings. The heating of the bat-
tery charger during the charging process can
pose a fire hazard.
Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If
contact accidentally occurs, flush with wa-
ter. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritations or burns.

Functional Description

Please unfold the fold-out page with the repre-
sentation of the measuring tool and leave it un-
folded while reading the operating instructions.

Intended Use

The measuring tool is intended for projecting
and checking precise horizontal partitions, verti-
cal lines, building lines and plumb points, for
both indoor and outdoor use.

Product Features

The numbering of the product features shown
refers to the illustration of the measuring tool
on the graphic page.
1 Spirit level
2 Reception lens for remote control
3 Socket for charge plug
4 Warning label, laser radiation exit opening
5 Exit opening for laser beam
6 Y-axis mark
7 X-axis mark
Bosch Power Tools
8 Plumb beam
9 Variable laser beam
10 Plumb notches, X-axis
11 Plumb notches, Y-axis
12 Latch of battery lid
13 Battery lid
14 Rubber foot
15 Battery pack
16 Laser warning label
17 Tripod mount, 5/8" (horizontal and vertical)
18 Serial number
19 Pushbutton for line operation and line
length selection
20 Upper direction pushbutton
21 Left direction pushbutton
22 Pushbutton for rotational operation and
selection of the rotation speed
23 Lower direction pushbutton
24 Right direction pushbutton
25 Manual levelling indicator "man"
26 Automatic levelling indicator "auto"
27 Battery charge control indicator
28 "man/auto" button for switching off the
automatic levelling
29 On/Off button
30 Construction laser measuring rod*
31 Laser viewing glasses
32 Wall holder/alignment unit*
33 5/8" screw on wall holder*
34 Knob screw of the alignment unit*
35 Measurement plate with stand
36 Ceiling measurement plate*
37 Inclination gauge*
38 High-performance receiver with holder
39 Remote control
40 Tripod*
41 Charge connector
42 Battery charger
43 Case
*The accessories illustrated or described are not in-
cluded as standard delivery.
