Product programme .................................................................. 3
DESCRIPTION .................................................................................. 3
MOUNTING ...................................................................................... 3
Mounting the OJ Zone Module ................................................... 3
Mounting the OJ RPT-20T Room Panel ...................................... 4
CONNECTING .................................................................................. 4
Connecting the Room Panel ...................................................... 4
Connecting sensors to the Room Panel ...................................... 5
CONFIGURATION ............................................................................. 6
Schedule menu ......................................................................... 6
Room data ................................................................................ 8
.............................................................................. 9
........................................................................ 10
........................................................................ 11
.................................................................. 12
........................................................................... 13
...................................................................... 15
....................................................................... 16
HELP ............................................................................................. 21
Alarm list ................................................................................ 22
Produktprogramm ................................................................... 25
BESCHREIBUNG ............................................................................ 25
EINBAU .......................................................................................... 25
Montage des OJ-Zone-Module ................................................ 25
Montage des OJ-RPT-20T-Raumbediengeräts .......................... 26
VERBINDUNGSAUFBAU ................................................................. 26
Anschluss des Raumbediengeräts ........................................... 26
Anschluss von Fühlern am Raumbediengerät ........................... 27
KONFIGURATION ........................................................................... 28
Zeitplan-Menü ......................................................................... 28
Raumdaten ............................................................................. 30
............................................................................... 31
...................................................................... 32
..................................................................... 33
................................................................ 35
....................................................................... 37
............................................................... 38
HILFE ............................................................................................ 43
Alarmliste ............................................................................... 44
2
© 2015 OJ Electronics A/S
........................................................ 34
COMISSIONING
OJ GreenZone™
Stand-alone
English
Used together, the OJ GreenZone Module and the OJ RPT-20T
Room Panel are capable of controlling temperature and ventilation
as a stand-alone system. These instructions describe the relatively
simple procedure for setting up the system and provide a
description of each function in the settings menu.
Product programme
OJ-Zone-Module-A
OJ-Zone-Module-M
OJ-Zone-Module-MP
OJ-RPT-20T
DESCRIPTION
By combining an OJ Zone Module with an OJ RPT-20T Room Panel,
temperature and ventilation air flow can be controlled without any
communication to a central air handling unit. This can be convenient
when, for example, one or more cabins are located away from the
main building. The system can be configured directly from the Room
Panel touchscreen. Although the Room Panel has a built-in room
temperature sensor, additional sensors can be added either to the
Zone Module or directly to the Room Panel.
The Zone Module comes in three different variants; all are equally
capable, but each is intended for a different VAV communication
interface. The OJ Zone Module Analogue uses mainly 0-10V signals.
There are also two digital versions, communicating with Modbus
and MP-Bus respectively.
All versions use Modbus to communicate with the Room Panel.
MOUNTING
Mounting the OJ Zone Module
The OJ Zone Module is designed to be mounted on a DIN rail. Avoid
direct exposure to sunlight. After initial setup, there is no need for
physical access to the OJ Zone Module and the unit can therefore
be mounted in concealed locations. Note though that the cable from
© 2015 OJ Electronics A/S
OJ Zone Module for Analogue
OJ Zone Module for Modbus
OJ Zone Module for MP-Bus
Room Panel with 2" Touchscreen
3
