U S E R M AN U A L
Type OCC3 / OCD3
57002 09/07 - (BJ)
Introduction
The thermostat is capable of switching on your heating system at pre determined times on different days of the week. It is possible to set 4 periods called
events each day with different temperatures. From factory a default schedule is programmed suitable for most installations. Unless you change these
settings the thermostat will operate to this default program.
Working with lower temperatures during times that the room is unoccupied will lower your energy costs without reducing the comfort. The thermostat has an
adaptive function that automatically changes the start time of a heating period so that the desired temperature is reached at the time that you set. After 3
days the adaptive function has learned when the heating must be switched on.
The thermostat has a built-in temperature sensor and an externally temperature sensor. In this configuration the thermostat controls the temperature within
the room and use the externally temperature sensor as limit sensor avoiding too high or too low temperatures in the floor construction.
The thermostat has a pin button marked R, allowing you to reset the thermostat to factory settings. These are listed at the end of this manual with space for
you to record your own weekly schedule.
The display is backlit when operating the buttons. The heating element is switched off when the light is on in the display.
The heating system can be switched off on the built-in interrupter. The Microprocessor taking care of the time will still be supplied with power whereby time
and day will be maintained. When the heating is required and the thermostat is switched on, it will continue the 4-event programme based on present time
and day.
1. Getting started
Buttons
A: B: C:
Pin button On/off Reset to
adjust of factory
clock setting
E: F: G:
OK - Adjustment Display
accept up
Setting the thermostat into operation
First time power is connected the clock and day will be flashing and must be set. If you need to
adjust the time of the thermostat at a later date, insert a pin into the hole
and day. Adjustment must be made for summer and winter time.
☞
Press the UP (
select the correct time and press OK button (
Then press the UP (
☞
select the correct day and press OK (
Type: OCC3 / OCD3
English
Display symbols
D: H:
Adjustment
Clock
down
function
L:
Heating on
for setting of time
) or DOWN ( ) buttons to
).
) or DOWN ( ) button to
) button.
H N
I
M
J
L
K
I: J:
Manual Time and
mode temperature
M: N:
% 4-event symbol
Monitoring
Wake
of switch-on
Night
time
1-7
K:
Day number
Out
Home
