Bose Virtually Invisible 191 Bedienungs- Und Installateuranleitung Seite 27

Figure 30
Pushing excess wire behind
the speaker
Figure 31
Positioning the speaker all
the way in the hole
To test the speaker:
1. Turn on the receiver/amplifier and play a piece of music that is familiar to you.
2. Listen for clarity and accuracy of the performance from one speaker.
• If you hear a problem, refer to "Troubleshooting" starting on page 32.
• If the performance sounds fine, test the other speaker, or continue with the installation
steps for this speaker.
When the connections are completed, push any excess wire into the hole behind the speaker
(Figure 30).
3. Make sure the frame of the speaker is firmly screwed onto the face. The frame prevents
the speaker from slipping all the way into the hole. Refer to Figure 23 on page 22 if you
need to reverse the frame to properly orient the Bose logo on the speaker face.
4. Now push the speaker into the hole until the face is straight and flush with the wall
(Figure 31).
Or
Steps to Installing
27
