Safety information for the operator

Danger!
Installation and electrical connections must comply with the na-
tional regulations. 1)
The electrical installation is to be fitted with an easily accessible
all pole isolating device (master switch) on the building side,
complying with overvoltage category III. This means that each
pin shall have a contact opening width complying with the con-
ditions of overvoltage category III for full isolation.
If it is connected via a plug and socket, the plug system in com-
pliance with EN 60309-1/A11; 5 pin; 400 VAC (35 A) is to used.
Assembly, installation, upgrading or repair of the device may
only be carried out by specially trained and instructed person-
nel.
• All danger and safety notes attached to the device must be observed!
• Please see Technical Data – see page 211 for the maximum permis-
sible weight for the acrylic glass panel.
• No safety equipment (e.g. panel switch) or safety warnings may be
removed or deactivated which would impair the safe operation of the
device!
• The device may only be operated in full working order!
1) In Germany: VDE regulations
98
• A timer must be designed so that the device is automatically switched
off at the latest after <110% of the selected operating time even when
the controller fails. The device operating time must therefore be dual
controlled with a timer that complies with EN 60335-2-27.
• Do not change, obstruct or block the air inflow and outflow area to the
device or make any unauthorised changes to the device. The manu-
facturer shall bear no liability for damage or injuries resulting from
such actions.
• The ventilation data in the Planning Manual must be observed without
fail (see page 212).
• The device should not be installed and operated on the transport pal-
let. If installed on the transport pallet, optimal alignment and adjust-
ment is not possible. Breakdown and malfunctions are unavoidable.
Caution!
The code for access via the infrared interface is preset in the
software of the hand-held unit, and can therefore be used with
any unit. Anyone, who downloads the software from the internet
can access the unit date with a hand-held unit. Please make
sure that customer service changes the preset access code pri-
or to initial start-up. Please make a note of the new code for later
use!
This code is independent of the access code for the presettings
via the control panel.
2) For JK timers see page 213
2)
