To reach 40ºC (104ºF), the heating duration required is base on the starting water temperature and ambient
temperature, the data below is purely for reference. To display the current water temperature, run the filter
system for at least a minute.
Ambient Temperature
10ºC(50ºF)
15ºC(59ºF)
20ºC(68ºF)
25ºC(77ºF)
30ºC(86ºF)
Be sure to cover the spa with the spa cover whenever the
heating function is activated. Leaving the spa uncovered will
increase the heating duration required.
Please do not use the spa when ambient temperature is
lower than 4ºC (39ºF).
Power Rate
Massage Tube Power
220-240V AC,
2,050W at 20ºC
Selected Location
WARNING: The selected location has to be able to support
of supporting the expected load.
WARNING: An adequate drainage system has to be provided
to deal with overflow water for both indoor and outdoor
installations.
IMPORTANT: Because of the combined weight of the Lay-Z-Spa, water, and users, it is extremely important
that the base where the Lay-Z-Spa is installed is smooth, flat, level and capable of uniformly supporting the
weight for the entire time the Lay-Z-Spa is installed (not on the carpet or other similar material). If the
Lay-Z-Spa is placed on a surface, which does not meet these requirements, any damage caused by improper
support is not covered under the manufacturer's warranty. It is the responsibility of the Lay-Z-Spa owner to
assure the integrity of the site at all times.
1. Indoor Installation:
Be aware of special requirements if you install the spa indoors.
• Humidity is a natural side effect with Lay-Z-Spa installation. Determine the effects of
airborne moisture on exposed wood, paper, etc. in the proposed location. To minimize these effects it is best to
provide plenty of ventilation to the selected area. An architect can help determine if more ventilation is needed.
2. Outdoor Installation:
• During filling, draining or when in use, water may flow out of the spa. Therefore the Lay-Z-Spa should be
installed near a floor drain.
• Do not leave the spa's surface exposed to direct sunlight for long periods of time.
PRCD Test
RESET
TEST
1
NOTE: Drawings for illustration purpose only. May not
reflect actual product. Not to scale.
1. Insert the plug.
2. Press the "RESET" button, the indicator light turns on.
3. Press the "TEST" button, the indicator light turns off.
4. Press the "RESET" button, the indicator light turns on.
5. Press the "On/Off" button for 2 seconds, your pump is ready to use.
WARNING: The PRCD plug must be tested before each use to avoid risk of electric shock.
WARNING: Before inserting plug into a power outlet, make sure the current rate of the power outlet is
suitable for the pump.
WARNING: Do not use the pump if this test fails and contact our Aftersales Service.
S-S-005855/14x21cm/54112; 54113; 54123; 54129; 54148; 54154; 54171; 54174; 54175; 54183; 54186/欧规AirJet SPA说明书/JS-YF-2016-B-16420/
IMPORTANT !
Water Temperature
10ºC(50ºF)
15ºC(59ºF)
20ºC(68ºF)
25ºC(77ºF)
30ºC(86ºF)
Heat Element Power
800W 2,000W at 20ºC

INSTALLATION

RESET RESET
TEST
TEST
2
3
Set Temperature Heating Duration
40ºC(104ºF) 18.5 h
40ºC(104ºF)
40ºC(104ºF) 11.5 h
40ºC(104ºF) 8.5 h
40ºC(104ºF) 5.5 h
Water Pump Power
50W
RESET
TEST
4
8
15 h
