Installing the Processor

8. Locate the processor socket.
9. Push the lever handle down and away from the socket to release it (see letter "A" in
Figure
10. Rotate the lever open all the way (see letter "B" in
11. Push the rear tab with your finger tip to bring the front end of the load plate open
slightly (see letter "A" in
12. Open the load plate (see letter "B" in
13. Remove the protective socket cover (see
Note: Do not touch the socket pins; they are very sensitive and easily damaged.
Note: Retain the protective socket cover for use when removing a processor that will not be
replaced.
20
10).

Figure 10. Lifting the Processor Socket Lever

Figure

Figure 11. Opening the Load Plate

Figure
A
B
AF002835
11).
Figure 11).
B
A
Figure 12).
®
Intel Compute Module MFS5520VI User Guide
10).
AF002836
