Hardware Installations and Upgrades
Before You Begin
Before working with your server product, review the safety and ESD information at the
beginning of this manual and in the appendices.
Tools and Supplies Needed
•
Phillips
•
1/4-inch nut driver
•
Anti-static wrist strap and conductive foam pad (recommended)
Installation Guidelines
Before installing options:
1. Observe the safety and ESD information at the beginning of this manual and in the
appendices.
2.
Remove the compute module from the chassis. Before doing so, you must first shut
down the operating system and turn off the compute module.
3.
Take note of the following color coding on components:
— Blue on a component indicates a touch point, where you can grip the component
— Green on a component indicates that the component may be hot-swapped. For a
Removing and Installing an Intel
Removing a Compute Module from the Chassis
To remove a compute module from the chassis, follow these steps:
1. Observe the safety and ESD information at the beginning of this manual and in the
appendices.
2.
If the compute module is operating, shut down the operating system and power it
down.
3.
Release the two retention levers by pressing on the release button located between
the two lever handles.
®
Intel
Compute Module MFS5520VI User Guide
*
(cross head) screwdriver (#1 bit and #2 bit)
to install or remove it from the server.
complete list of installation or removal steps, see the instructions included with
the hot-swap component.
®
Compute Module MFS5520VI
13
