Deep pots are loaded on slant to allow water to run out of them.
The bottom basket has folding stands enabling the loading of
large pots and pans.
GB
H
9
G
9
Folding racks of the upper and lower basket
Folding tines consist of two parts. Folding the racks in the lower basket (for 60 cm dishwashers), the upper and
lower baskets (for 45 cm dishwashers), as shown in the fi gure, will create more space for storing larger pots and
pans. If necessary, each part can be folded separately, or both parts can be folded together to create a large
load area in the lower basket.
1
Lower basket for 45 cm dishwashers
90
60 cm dishwasher
F. Bowl
G. Soup plate
H. Shallow plate
I. Desert plate
J. Oval platter
F
H
I I
1 8 1
J
G G
2 1
Upper basket for 45 cm dishwashers
1
2
45 cm dishwasher
F. Bowl
G. Soup plate
H. Shallow plate
I. Desert plate
J. Oval platter
Lower basket for 60 cm dishwashers
2
1
