Control Panel - ECG EDF 4527 QWA++ Bedienungsanleitung

GROUNDING OF THE APPLIANCE
• This appliance must be grounded. In the event of a failure or accident,
grounding reduces the risk of electric shock. The appliance is
equipped with a three core power cable with a plug with grounding
contact. In accordance with local laws and directives, the power
cord must be connected to a properly grounded power outlet.
Improper connection of the grounding conductor may increase the
GB
risk of electric shock.
• If you are not convinced about proper grounding of the appliance,
contact a qualifi ed technician. If the power cord plug of the device
does not match your wall outlet, ask a qualifi ed technician for
replacement.
DESCRIPTION

Control panel

1. Switch: Switching the appliance on and off .
2. Program selection button: Select the required program by pressing the button repeatedly. The selected
wash program is signalled by the corresponding light coming on.
3. Half Load button /Dry+*: By pressing this button, you can select the additional functions: half load, extra
drying or both functions at once.
4. Delay start button/child lock: You can delay the start of the program by up to 24 hours by pressing this
button. You can activate the child lock by pressing this button for at least 3 seconds, "LO" fl ashes 6 times
on the display.
5. START/PAUSE button: Press this button to start or to pause the washing.
6. Selected program indicators: The selected program is indicated by the relevant indicator light.
7. Half load indicator: This indicator lights up if you activate the additional function "Half load".
8. Dry+ indicator: This indicator lights up if you activate the additional function "Dry+".
9. Rinse-aid refi ll indicator: Lights up when you need to refi ll the dispenser.
* Dry+: By selecting this additional function, the drying time will be extended by another 5 minutes after
the program has fi nished for a better drying result.
80
6
1 2 3 4 5
