5. OVERLAP DISTRIBUTION
The overlap, or the difference in width between the
panel to be edge banded and the width of the strip
being used, is distributed as follows:
1. Fixed side:
The overlap on this side will be 1.5 mm, or there will
be no overlap, depending on the way the clamp on the
fixed side has been adjusted (see clamps section) (Fig. 5).
2. Moving side:
A) All the overlap will remain on this side of the panel,
if the fixed side clamp I has been adjusted "FLUSH WITH
THE BOARD". (Fig. 5).
B) If the fixed side clamp has been adjusted "WITH AN
OVERLAP", all the overlap except for 1.5 mm (Fig. 5)
will remain.
6. EDGE BANDING
1. Place the tool at the beginning of the panel, making
sure that the pre-glued strip exceeds the panel end by
at least 1 cm: (Fig. 6).
2. Set the switch to position I or II to start up the heater
and wait for a few seconds until the rated temperature
is reached and the strip glue starts to melt.
3. Press the pre-glued strip against the panel, by pushing
on knob M, (Fig. 7), and move the machine along the
panel; (Figs. 6 and 7).
4. Operate the cutting lever when the clamp reaches the
end of the panel, with an overlap of 2 cm on this side
and continue edging until the end; (Fig. 8).
NOTE. - The heater has two output temperatures (switch
positions I and II): 300°C and 525°C (570°F and 1000°F).
Use one or the other depending on the advance speed
at which you are edging and the quality of the glue on
the pre-glued strip you are using

7. MAINTENANCE

Before performing any maintenance operation, discon-
nect machine from power source.
Changing blades:
Remove screw N, (Fig. 4), which secures the blade block
to the gluing roller. Turn the machine over and loosen
the three screws P, (Fig. 6), that hold it to the fixed side.
Separate the blade block from the machine; (Fig.9).
Remove strip guide Q, (Fig. 9), deflector R and rear
blade S, (Fig. 10).
The heads of screws T, (Fig. 9) securing the front blade
can be seen at the top of the blade block. Loosen and
remove these screws, releasing the front blade.
Change the blades and re-assemble the blade block
in the opposite order to that given for dismantling it.
8. OPTIONAL ACCESSORIES
5246025- Inclined roller (4°), for edging inclined
doors, etc,
9. NOISE AND VIBRATION LEVEL
The noise and vibration levels of this device have been
measured in accordance with European standard EN
60745-1 and serve as a basis for comparison with other
machines with similar applications.
The indicated vibration level has been determined for
the device's main applications and may be used as an
initial value for evaluating the risk presented by expo-
sure to vibrations. However, vibrations may reach levels
that are quite different from the declared value under
other application conditions, with other tools or with
insufficient maintenance of the electrical device or its
accessories, reaching a much higher value as a result
of the work cycle or the manner in which the electrical
device is used.
Therefore, it is necessary to establish safety measures
to protect the user from the effects of vibrations, such
as maintaining both the device and its tools in perfect
condition and organising the duration of work cycles
(such as operating times when the machine is subjected
to loads, and operating times when working with no-load,
in effect, not in use, as reducing the latter may have a
considerable effect upon the overall ex

10. WARRANTY

All VIRUTEX power tools are guaranteed for 12 months
from the date of purchase, excluding any damage which
is a result of incorrect use or fo natural wear and tear
on the machine. All repairs should be carried out by the
official VIRUTEX technical assistance service.
11. RECYCLING ELECTRICAL EQUIPMENT
Never dispose of electrical equipment with domestic was-
te. Recycle equipment, accessories and packaging in ways
that minimise any adverse effect on the environment.
Comply with the current regulations in your country.
Applicable in the European Union and in European
countries with selective waste collection systems:
If this symbol appears on the product or in the accom-
panying information, at the end of the product's useful
life it must not be disposed of with other domestic waste.
In accordance with European Directive 2002/96/EC, users
may contact the establishment where they purchased the
product or the relevant local authority to find out where
