Preparation For Operation - GRAPHITE 59G824 Betriebsanleitung

MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY/SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Leg
2. Screw + leg locking knob
3. Fence
4. Screw + washer
5. Vertical clamp
6. Cutting blade shield
7. Mitre gauge
8. Ripping fence
9. Push stick
10. Dust bag
11. Screw + nut
12. Hexagonal key
Remove power cord plug from mains socket before working at the device.
Flip over saw is supplied disassembled. Take items out of the package and assemble in the below described
order.
FLIP OVER SAW ASSEMBLY
● Tilt the saw slightly to the side.
●
Use the screws and leg locking knobs (
●
Set up the adjustable feet (
DUST EXTRACTION
To install the dust bag (39) slide it firmly onto the dust extraction outlet (40) (when operating in mitre saw
mode) (fig. B). To empty the dust bag (39), remove it from the dust extraction outlet (40) and open the zip-
fastener that allows to access inside the bag. Whenever more efficient dust extraction is required especially
for health hazardous carcinogenic dusts, attach hose of suction device directly to the dust extraction outlet
(40) (when using in table saw mode) or outlet in the cutting blade bottom shield (7) (when using in mitre
saw mode).
Empty the dust bag on a regular basis to avoid overfill. To achieve optimal dust extraction empty the
bag when it is 2/3 full.
INSTALLATION AND REMOVAL OF CUTTING BLADE BOTTOM SHIELD
When in mitre saw mode, the cutting blade bottom shield must be installed to cover lower part of the
cutting blade.
● Install the cutting blade bottom shield (7) and fasten with screws (fig. C).
●
Remove the cutting blade bottom shield (
TRANSPORT
Before moving the tool follow the procedure:
●
Set up the tool in table saw mode.
- 4 pcs
- 4 sets
- 1 pce
- 2 sets
- 1 pce
- 1 pce
- 1 pce
- 1 pce
- 1 pce
- 1 pce
- 1 set
- 2 pcs

PREPARATION FOR OPERATION

21) (included) to attach the legs (22) to the base (fig. A).
23) so the flip over saw stands firmly.
7) before operating in table saw mode.
26
