Quick start-up

Control panel

Online mode

Online Trac.1
Tear

Offline mode

Offline Trac.1
Park LF/FF

Setup mode

Adjust Paperway
Menu Char
You can control printer operation using the control panel and the keys.
The first line of the display informs you about whether the printer is in
mode and about the paper path selected
When switching on the printer, it automatically selects Online mode. It can receive data from the
computer only in this mode.
Online Sets the printer to Offline mode.
Sets the printer to Setup mode.
Tear key: Activates the tear function when fanfold paper is loaded
Setup
(see page 15). If Load is displayed above this key, no paper is loaded in
the printer; press the key to feed paper to the printing position.
Step feeds, line feeds and form feeds can be performed via the control panel only in this mode
(see page 15).
Sets the printer to Offline mode.
Online
Sets the printer to Setup mode.
If no paper is loaded:
Setup
Short keypress: Line feed (LF)
Long keypress: Form feed (FF)
Short keypress: Micro-step return
Long keypress: Constant paper feed return
Short keypress: Micro-step forward
Long keypress: Constant paper feed forward
Clears the paper path with paper loaded and activates paper path quick
selection (see page 14).
Sets the printer to Setup mode. In this mode, the following settings are
Online
available:
Sets the font and the number of characters per inch (Char menu).
Setup
Paper path (Paperway menu)
Tear position and first printing line
Other menu settings (Menu)
Access to the other menu options is disabled by the manufacturer. For information on how to
enable access to these options as well as about the options available, refer to the online docu-
mentation on the CD-ROM, chapter 1, Operation
(Trac.1 or Single).
Load key (see above). If paper is loaded:
(Adjust menu)
(Unlock the menu mode).
Control panel
Online or in Offline
7
