Fine filter, polyester, area [m
Efficiency, fine filter, EN 60335-2-69, Class M [%]
Filter area, HEPA filter [m
Efficiency, fine filter, EN 60335-2-69, Class H [%]
Filter classification, EN 1822-1
Sound level [dB(A)]
Pressure generation and air flow
*/ Sound pressure level at 1.6 m height and 1 m distance according to DIN EN ISO 3744 in free field measurement at maximum
air flow.

Operation

Connection
Connect the machine to an electrical outlet with a voltage as per the machine's rating plate specifications. If using an extension
cord, it must be water-resistant.
Always check that the electrical equipment and cables for the equalization are undamaged and that all accessories are antistatic.
Connect the plug to an electrical socket outside the zone with voltage as specified on the machine's marking.
The material is separated into a container attached directly to the cyclone. The filter is cleaned using reverse pulse. The
separated and filtered material is collected into a container with a plastic sack insert, see consumables. The container can easily
be removed from the machine by releasing the fasteners, which makes it easy to take the material away.
CAUTION
The container is held in place by fasteners which means that a clamp must be placed on the machine's
grounding braid. This is ensured by aligning the opposite red arrow markings.
Emptying
The container underneath the cyclone should be emptied when about 2/3 full.
Be careful when releasing the fasteners – they can open with great force – especially when the material is heavy. Be aware that
emptying the container may pose a risk of explosion, i.e. that an explosive atmosphere may occur and that static charge may be
generated by the friction of the particles against the container. For appropriate measures, see CENELEC TR 50404.
When the container is to be emptied, the two fasteners must be carefully released, one at a time, to prevent dust from swirling up
unnecessarily. When the machine's container has been lowered, turn on the separator again so that any stuck particles are
sucked into the filter cyclone.
16
2
]
2
]
1800/2800 H EX, Art.nr. Part 94169-H
DC 1800H EX DC 2800H EX
1,5 1,5
99,9 99,9
0,85 0,85
99,995 99,995
HEPA H13 HEPA H13
70 70
