Digital & Pulsing Mini Vortex Mixer Control Panel - OHAUS Vortex series Bedienungsanleitung

D & P m v
igital ulSing ini ortex
B
C
A
* Same controls for the Digital Mini Vortex Mixer but without the 'pulse' button.
5 5
m c P
ixer ontrol anel
The front panel of the Digital/Pulsing Mini Vortex Mixer contains all the switches,
controls and displays needed to operate the unit.
A. 3-way rocker switch: Auto/standby/on rocker switch starts/stops the vortexing
function.
B. Time display: Displays accumulated time (continuous mode) or how much time is
remaining (timed mode). The display range is from 0 to 9,999 minutes in one (1)
second increments. The display will indicate minutes and seconds until the timer
reaches 99 minutes and 59 seconds (99:59), then the display will automatically
display minutes up to 9,999.
D C. Up/down arrows for set-point control.
D. Speed display: Displays the speed of the Mini Vortex Mixer.
E. Up/down arrows for set-point control.
F. Pulse button: Starts the pulsing mode.
E
F
EN
