> Push the shaft into the inner tube (5) and push it firmly into position.
5
> Slightly turn the closed bearings (6) to make sure that the shaft can easily be
moved.
> Push the assembled inner tube into the outer tube.
> Push the lower bearing housing (7) over the mounting tip into the outer tube (by
hand), so that it engages in the catches (8).
> Use an appropriate screwdriver to hold the shaft on the motor side (9).
> Unscrew the mounting tip.
> Screw the impellor (10) on.
> Screw the base piece (11) closed manually.
The pump is now ready to use.
10 / 16
6
7
8
9
11
Attachment Sanitary Pump F 427
10
