Commissioning

2.6. Mounting the door intercom

Prepare the on-wall housing for the cable inlet
Fix the housing and connect the door intercom
Insert the door intercom into the housing and use the four
screws to fix it to the on-wall housing. Then mount the
screw covers – done!
55
The example shown is an on-wall installation.
The door intercom may alternatively also be
installed in-wall. To do so, the in-wall housing
will be installed flush with the plaster into the
wall cavity. Afterwards, use the sealing and
the included screws and screw covers to install
and fix the door intercom station into either the
on-wall or in-wall housing. Please make sure to
use an appropriate dry wall cavity (cf.
www.myintercom.de/downloads/datenblaetter)
when installing the device in a dry wall (e.g. in a
gate post, supporting metal casings or the like).
For such an installation, corresponding con-
struction measures need to be taken to guaran-
tee that absolutely no condensation can form
inside the myintercom remote station.
Use the provided fixation material (screws and
screw covers) to fix the device to a level support
underground. Please note: The provided sealing
must be put in place first. It needs to be in full
contact with the level underground.
