– if the appliance starts to vibrate abnormally
(check immediately).
4. Maintenance and storage
• Keep all nuts, bolts, and screws tight to be sure the
appliance is in safe working condition.
• Check the grass catcher frequently for wear or de-
terioration.
• Replace worn or damaged parts for safety.
• For rotary mowers, ensure that only replacement
cutting means of the right type are used.
– Never store the equipment with petrol in the
tank inside a building where fumes can reach
an open flame or spark;
– Allow the engine to cool before storing in any
enclosure;
– To reduce the fire hazard, keep the engine, si-
lencer, battery compartment and petrol storage
area free of grass, leaves, or excessive grease;
– If the fuel tank has to be drained, this should be
done outdoors.
Special safety warning
1. Grip the handles of the brush cutter firmly with
both hands. If you suspend the work, place the
throttle into the idling position.
2. Always be sure to maintain a steady, even pos-
ture while working
3. Maintain the speed of the engine at the level re-
quired to perform cutting work and never raise
the speed of the engine above the necessary
level.
4. If the grass gets caught in the blade during op-
eration, or if you need to check the unit or refuel
the tank always be sure to turn off the engine.
5. If the blade touches a hard object like a stone im-
mediately stop the engine and check if something
is wrong with the blade. If so, replace the blade
with a new one.
6. If someone calls out while working, always be
sure to turn off the engine before turning around.
7. Never touch the spark plug or plug cord while the
engine is in operation. Doing so may result in be-
ing subjected to an electrical shock.
8. Never touch the muffler, spark plug or other me-
tallic parts of the engine while the engine is in
operation or immediately after shutting down the
engine. Doing so may result in serious burns.
9. When you finish cutting in one location and wish
to continue working in another spot, turn off the
engine and turn the machine to have the blade
facing away from your body.
10. Check that the cutting attachment stopped turn-
ing under the engine idle before starting to use
the machine.
22 GB

6. Technical data

BCH3200PB4
Technical data
Cutting data grass trimmer
Cutting circle
diameter of line mm
Cutting line diameter
mm
Cutting line length m
Max. cutting speed
max. min
-1
Cutting data brush cutter
Cutting circle
diameter of blade mm
Cutter balde
thickness mm
Teeth quantity
Max. cutting speed
max. min
-1
Power unit
Displacement cm³
Max. engine output
kW
720, Normal petrol / Lead free
Fuel tank capicity cm³
max. 5% bioethanol
Oil capicity cm³
Oil
Engine type 4-stroke engine, air-cooled
Weight kg
Subject to technical changes!
Information concerning noise emission measured ac-
cording to relevant standards:
Sound pressure L = 97,1 dB(A)
pA
Sound power L = 105,4 dB(A)
WA
Uncertainty K = 3 dB(A)
PA
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Vibration:
Grass trimmer: A = 5,073 m/s
hv
Brush cutter: A = 4,771 m/s
hv
Uncertainty K = 1.5 m/s
2
PA
Reduce noise generation and vibration to a minimum!
• Use only equipment that is in perfect condition.
• Maintain and clean the equipment regularly.
• Adopt your way of working to the equipment.
• Do not overload the equipment.
• Have the equipment checked if necessary.
• Switch off the equipment when not in use.
• Wear gloves.
In these operating instructions we have marked
the places that have to do with your safety with
this sign: m
430
2 x 2,4
4
6200
255
1,4
3
7300
31,0
0,7
100
10W30 / SAE30
7,8
2
2
