Ottobock 17H50 Coxa Stable Gebrauchsanweisung Seite 6

Date of the last update: 2013-12-02
• Please read this document carefully.
• Follow the safety instructions.
1 Application
The Ottobock Hip Orthosis is to be used solely for the orthotic fitting of the hip joint.
2 Indication and Effects
The orthosis stabilizes the hip after total hip prosthetic replacement or correction. The orthosis
provides stabilization of the hip by restricting rotation and limiting thigh movement. Specific in-
dications must be determined by the physician.
3 Size Selection
The hip orthosis consists of the following three main components: 28L50 Hip Module (fig. 1,
item 1), 28L51 Thigh Module (fig. 1, item 2) and 17H50 Hip Joint (fig. 1, item 3) which are indi-
vidually combined in accordance with the patient's measurements.
28L50 Hip Module
Art. no. Side
28L50=R-S Right
28L50=L-S Left
28L50=R-M Right
28L50=L-M Left
28L50=R-L Right
28L50=L-L Left
28L51C Thigh Module
Art. no. Side
28L51=R-S Right
28L51=L-S Left
28L51=R-M Right
28L51=L-M Left
28L51=R-L Right
28L51=L-L Left
6 | Ottobock
Size Waist circumf. (A)
Small 60-82 cm
Medium 80-96 cm
Large 94-115 cm
Size Proximal thigh
circumference (C)
Small 44-53 cm
Medium 48-60 cm
Large 57-68 cm
Hip circumf. (B)
68-90 cm
90-110 cm
106-126 cm
Distal thigh
circumference (D)
34-41 cm
36-45 cm
42-49 cm
117550
