6. Installation

The given operating and performance features can only be guaranteed with the use of ENTREMATIC
accessories and safety devices.
Unless otherwise specified, all measurements are expressed in mm.

6.1 Preliminary checks

Check that the structure is sufficiently rugged and that the hinge pivots are properly lubricated.
Provide an opening and closing stop.
Position tail bracket [14] on to the pillar to check installation measurements and secure it.
The installation measurements indicated in the table allow you to choose the values of [A] and [B] on
the basis of the desired opening angle and in relation to the on site spaces and overall dimensions.
NOTE: The measurements [A] and [B] must be the same, in order to have a regular moviment.
Increasing [A] decreases the coming up speed during opening.
Reducing [B] increases the extent of gate opening.
Measurements [A] and [B] must in any case be compatible with the useful travel of the piston so
that; if [A] is increased, [B] must be decreased and vice versa.
[*] Use measurements between minimum and maximum values
A*
LUXO3B min 105
LUXO3BH max 160
LUXO4BH
LUXO5B min 130
LUXO5BH max 200
LUXO5VBH
D
B* A
130
105
min 130
max 170
130
160
170
200
min 170
max 290
200
130
A
L
min 60
B C
170 100
140 70
130 60
130 50
170 100
200 130
170 100
290 220
26
D E
90°
90°
90
95°
110°
90°
95°
120
120°
90°
L
760
910
